Chishing Shuttle Digital Control Quilting Machine

Specifications

CSDS128"-2 digital control quilting machine

1. D: Digital control; S: Small shuttle (HQ7 Japaneseshuttle )
2.128": 128inch width (3251mm)
3.2: Two needle row
4. Overall dimentions: 5500*1100*1600mm
5: Weight: 4000kg
6: Running speed: 200-500r/m .
7: Needle distance: 25.4mm .
8. Rating power: 6.2kw .
9. Thickness: ≤30mm .
10. Max. Pattern size: 6inch by 6inch .
*This quilting machine Adopting digital control program.

*Saddles and rollers driven by Panasonic servo devices.

*The revolution of the spindle controlled by panasonic frequency conversion control devices.

*Large number of built-in quilting patterns for your choice.

*Easy and quick make new designs.

*360 degrees quilting .

*Tack and jump function included .

*stitches between 2mm-6mm adjustable.

*Function of pattern compensation, an effective solution to the distortion of patterns when quilting thick materials.

*Simulation display of quilting.

*Automatic needle raising and location brake system.

*Function of automatic stop on breaking of thread(optional) .

*Infrared sensors to guarantee the safety of the operator .
