Lock Stitch Shuttle Multi Needle Quilting Machine(CSDB94"-3)
- shenzhen port
- T/T
You May Like
Product Details
| Condition | New | Brand Name | Chishing | |
| Model Number | CSDB94"-3 | Max Sewing Speed | 400-600r/m | |
| Max Sewing Thickness | 30mm | Number of Head | Single Head | |
| Moving Style | Frame Moved | Voltage | 380V/50HZ 220V/60HZ | |
| Power(W) | 3.5kw | Dimension(L*W*H) | 4.6*1.1*1.65m | |
| Weight | 3000kg | Certification | CE SGS Certification | |
| Warranty | One Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
CSDB94"-3 digital control quilting machine
1. D: Digital control model; B: Big shuttle (HQ10)
2.94": 94inch width (2388mm)
3.3: Three needle row .
4. Overall dimentions: 4700*1200*1650mm ..
5: Weight: 3400kg .
6: Running speed: 200-500r/m .
7: Needle distance: 25.4mm .
8. Rating power: 3.5kw .
9. Thickness: ≤30mm.
10. Max pattern size is 12inch by 12inch .
11. The shuttle size is HQ10 (japanese).
Functions & Features
*This quilting machine Adopting digital control program.
*Saddles and rollers driven by Panasonic servo devices.
*The revolution of the spindle controlled by panasonic frequency conversion control devices.
*Large number of built-in quilting patterns for your choice.
*Easy and quick make new designs.
*360 degrees quilting .
*Tack and jump function included.
*stitches between 2mm-6mm adjustable.
*Function of pattern compensation, an effective solution to the distortion of patterns when quilting thick materials.
*Simulation display of quilting.
*Automatic needle raising and location brake system.
*Function of automatic stop on breaking of thread(optional).
*Infrared sensors to guarantee the safety of the operator.
