Specifications
Quilting machine:the 110 inch width quilting is the ideal choice to process the quilts and comforters etc.CSDB110"-3 digital control quilting machine
1. D: Digital control model; B: Big shuttle (HQ10)
2.110": 110inch width (2794mm)
3.3: Three needle row
4. Overall dimentions: 5300*1200*1650mm
5: Weight: 3800kg
6: Running speed: 200-500r/m
7: Needle distance: 25.4mm
8. Rate power: 4.2kw
9. Thickness: ≤30mm
10. Max pattern size is 12inch by 12inch
11. The shuttle size is HQ10 (japanese)
*This quilting machine Adopting digital control program.
*Saddles and rollers driven by Panasonic servo devices.
*The revolution of the spindle controlled by panasonic frequency conversion control devices.
*Large number of built-in quilting patterns for your choice.
*Easy and quick make new designs.
*360 degrees quilting .
*Tack and jump function included.
*stitches between 2mm-6mm adjustable.
*Function of pattern compensation, an effective solution to the distortion of patterns when quilting thick materials.
*Simulation display of quilting.
*Automatic needle raising and location brake system.
*Function of automatic stop on breaking of thread(optional).
*Infrared sensors to guarantee the safety of the operator.
