Home > Instruments & Meters > Test Instrument > Test Machine > CTM-500S Concrete Creep Compression Testing Machine (Spring-loaded,Digital)
CTM-500S Concrete Creep Compression Testing Machine (Spring-loaded,Digital)
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GEOTEST EQUIPMENTS
Model Number:
CTM-500S
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai Negotiable
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CTM-1000MC Manhole Cover Compression Testing MachineNegotiableMOQ: 1 Set -
UTM-B Universal Testing Machine Construction MachineryNegotiableMOQ: 1 Set
-
CTM-2000B/3000B Tensile Compression Testing Manchine PriceNegotiableMOQ: 1 Set
-
CTM-2000 Universial Mechanical Properties Test ManchineNegotiableMOQ: 1 Set
-
WDT-30 Welding Drop Testing MachineUS$ 1 - 34652MOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
GEOTEST EQUIPMENTS
Model Number
CTM-500S
Power
Electronic
Usage
Universal Testing Machine
Specifications
Universal Testing Machine1.Dial gauge type
2.High precision and easy to operate
3.Steady working
4.Reliable results
CTM-500S Concrete Creep Compression Testing Machine (Spring-loaded,Digital)
Characteristics:
a. Used for determine the compressive creep deformation of the cylinder or rectangular solid concrete specimens under constant loading (relations between deformation and time).
b. It is suitable for concrete creep test under uni-axial compression at the condition of constant-temperature and constant-humidity.
| Model | CTM-500S | |||||
| Capacity | 500KN | |||||
| Accuracy | ±1% | |||||
| Spring height | 355mm | |||||
| Spring compression travel | 55mm | |||||
| Maximum vertical clearance | 1500mm (span between upper and lower platens) | |||||
| Power supply | 220V, 50Hz, 1ph. | |||||
| Overall dimensions | 600x600x2700mm | |||||
| Weight approx | about 800kg | |||||
