TTM Series Computer Controled Electrical Torque Torsion Testing Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Geotest Equipments
Model Number:
TTM
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai Negotiable
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UTM-S Computer Control Electronic Single Column Universal Tensile Testing MachineUS$ 6,900 - 7,600MOQ: 1 Set -
UTM-600B Automatic Universal Testing Machine (Computer Control Electro-hydraulic Servo )NegotiableMOQ: 1 Set
-
SRTM-300 Strand Wire Tensile Stress Relaxer TesterNegotiableMOQ: 1 Set
-
TTM-W Electronic Plastic Deformation Torsion Test EquipmentNegotiableMOQ: 1 Set
-
CTM-MC Manhole Cover Compression Stength TesterNegotiableMOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
Geotest Equipments
Model Number
TTM
Power
Electronic
Usage
Torsion Tester
TTM Series Computer Controled Electrical Torque Torsion Testing Machine
Used to determine static mechanical properties for metallic,non-metallic and other component such as transmission shaft,half shaft,etc. Thisserie of Computer Controled Laboratory Electrical Equipment Torsion Testing Instrument has 4 different models for your chioce which can meet different needs.To choose this " Computer Controled Laboratory Electrical Equipment Torsion Testing Instrument "will not make you disppointed.
| Model | TTM-50/100/200 | TTM-500/1000 | TTM-2000 | TTM-3000 |
| Capacity | 50/100/200Nm | 500/1000Nm | 2000Nm | 3000Nm |
| Max.distance betwwen the clamping head | 300mm | 600mm | 650mm | 200-1000mm adujustable |
| Central height of main shaft | 100mm | 170mm | 200mm | ≥120mm |
| Sample Size | Φ8- Φ10 | Φ8- Φ20 | Φ8- Φ28 | As required |
| Motor Power | 0.4KW | 0.75KW | 0.85KW | 3KW |
| Class | Class 1 |
| Range | 2%-100%F.S |
| Accuracy | ± 1% |
| Repeatability | ≤1% |
| Torsion derection | 0-9999° |
| Torsion angle resolution | 0.01° |
| Measuring range | About 4.2-5800000Pa.S |
| Torsion dierection | Bidirection Torsion |
| Power Supply | 220V,50HZ |
| Certificate | ISO9001:2008 and any other certificates you need can be provided |
| Delivery Time | For sample order with 3 working days for general order with 5-15working days |
| Standards | BS.EN.ASTM |
