General Instruction
The pull tester has been designed to detecting the tensile pulling force of anchor, anchor wire, steel bar, plug bolts and other anchoring pieces.
It is the necessary equipment for construction quality inspection.
It is consist of hand pump (or electric pump), hydraulic cylinder, digital indicator (KN) and high-pressure rubber pipe.
Hand pump is of duplex oil path (high-pressure and low-pressure) and plunger type with advantages such as high working efficiency, fast loading. Low-pressure can be adjusted according to the required pressure. There’s 3-position 4-way diversion valve to exchange the input and output oil path. The valve is of end face seal structure, it is of good sealing performance, easier to operate and long service life.
Hydraulic cylinder is of hollow duplex oil path, it is connected with the high-pressure rubber pipe through quick coupling.
Digital indicator is installed on the pump body. The pulling force can be directly read and converted.
The pull tester has features such as novel structure, reliable performance, small size, light weight and easy to carry.
Packing list
1. Hydraulic cylinder: 1 set
2. Hand Pump: 1 set
3. Digital indicator: 1 pc
4. High-pressure oil pipe: 2 pcs (with quick coupling)
Alternative technical specifications
Anchor device | Suitable for steel bar | Complete set of anchor device: ∅6, ∅8, ∅10, ∅12, ∅14, ∅16, ∅18, ∅20, ∅22, ∅25, ∅28, ∅32 |
Tensile rods Adapter | Suitable for bolts and screws | Complete set of adapter: M6, M8, M10, M12, M14, M16, M18, M20, M22, M24 Specifications of tensile rods: M12, M18, M24 |
| Hand pump | Working pressure | 63 MPa (high-pressure) | |||||
| 2 MPa (low-pressure) | |||||||
| Flow | 2.3 ml / time (high pressure, adjustable) | ||||||
| 14.5 ml / time (low-pressure) | |||||||
| Maximum pressure | 500 N | ||||||
| Amount of oil storage | 1.5 L | ||||||
| Quality | 12 kg | ||||||
| Hydraulic cylinder | Working capacity | 500 KN | |||||
| Tensile travel | 80 mm | ||||||
| Central aperture size | Diameter 45 mm | ||||||
| Quality | 23 kg | ||||||
