Home > Instruments & Meters > Test Instrument > Test Machine > BTM-40 Stainless Steel Bar Tube Bending Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Geotest Equipments
Model Number:
BTM-40
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai Negotiable
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CTM-600MC BS EN124 Standard Hydraulic Servo System Computer Controlled Manhole Cover Compression Testing MachineNegotiableMOQ: 1 Set -
TTM Series Computer Controled Electrical Torque Torsion Testing MachineNegotiableMOQ: 1 Set
-
UTM-S Computer Control Electronic Single Column Universal Tensile Testing MachineUS$ 6,900 - 7,600MOQ: 1 Set
-
UTM-600B Automatic Universal Testing Machine (Computer Control Electro-hydraulic Servo )NegotiableMOQ: 1 Set
-
SRTM-300 Strand Wire Tensile Stress Relaxer TesterNegotiableMOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
Geotest Equipments
Model Number
BTM-40
Power
Electronic
Usage
Bending Testing Machine
BTM-40 Stainless Steel Bar Tube Bending Machine
Used in bending performance test of steel bar.
BTM-40 Stainless Steel Bar Tube Bending Machine
| Diameter of steel bar | Φ40mm | |||||
| Rated pressure of oil cylinder | F=300KN | |||||
| Piston travel | S=250mm | |||||
| Rising speed of piston | V1=80mm/min | |||||
| Dropping speed of piston | V2=160mm/min | |||||
| Distance between two columns | 440mm | |||||
| Effective test space | 400mm | |||||
| Standard bending accessory | Φ60mm | |||||
| Power supply | 380V, 3 phase | |||||
| Overall dimensions | 640x400x1450mm | |||||
| Weight approx | 500kg | |||||
Construction Steel Bar Bending Machine
