RSTM-G LCD Display Servo Ring Stiffness Flexibility Tester

RSTM-G LCD Display Servo Ring Stiffness Flexibility Testerine

ASTM D2412, BS5480

Function:

1.The machine has large test space, applicable to pipes less than 3000 mm, mainly used to measure ring stiffness, ring flexibility, flattening, deflection properties.

2.With precise automatic control and data acquisition system to realize full digitalization adjustment to data acquisition and control process.

3.During test, the bearing load, compression deformation and other technical indexes can be measured.

4.After tensile test, the above parameters can be calculated automatically through main controller according to the test parameters, which are set before test and meantime display the corresponding test results. All test parameters can be saved and inquired after test, also can be connected with printer to print test reports.

Features:

1.with remote control box to realize speed adjustment of crossbeam, flexibly and freely switched;

2.with function of automatic return to original position, intelligently, efficiently, quickly;

3.with limit protection function of any working position and over voltage, over current protection functions, reliable, safe;

4.with strong test data, which can save, inquire and retrieve test data anytime.

5.with many control modes of constant speed control to force, stress, deformation, strain, stroke, load,

elongation, displacement and low cycle and user self-programming control;

6.switch among many test curves: stress-strain curve, load-deformation curve, load-displacement curve, load-time curve, deformation-time curve, displacement-time curve, load-strain curve. Partial enlargement, overlap and comparison.

Technical parameters:
