Cold Floor Deck Roll Former Machine

Hangzhou Roll Forming Machinery Co.,Ltd

Cold Floor Deck Roll Former Machine thumbnail-2

Cold Floor Deck Roll Former Machine photo-1

Cold Floor Deck Roll Former Machine photo-2

Negotiable MOQ: 1 Bag (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Business Type:

Association

Year Established:

2007

Main Markets:

North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, Domestic Market

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

This Cold floor deck roll former machine is the special equipment for continuous rolling and cold-forming on steel sheet.

Deck floor roll forming machine adopts coiling steel sheet as the raw material, declination, then continuous rolling and cold

forming, automatically cut to the size and output the finished panel to the supporter.

The Cold floor deck roll former machine adopts PLC control, AC frequency and speed adjusting technology, and it realizes the continuous automatically production,

therefore, it is really a new type of energy-saving and high-effective producing equipment for steel structure.

Working process for Cold floor deck roll former machine

Decoil → Guiding system → Roll forming → Post Cutting → Output the finished products to supporter

Technical Parameters for the Cold floor deck roll former machine

Item			Parameter	Remark
Suitable Material	Type		Galvanized steel
	Width(mm)		1250mm
	Thickness(mm)		0.8-1.2
	Yield strength(Mpa)		230-300
	Coil capacity(T)		10 tons
Forming Speed(m/min)			About 20m/min	Not including cutting time
Roller Material			No.45 steel	With hard chrome painted.
No of Roller station			About 30sets	Depend on final design
Roller shaft diameter			About 90mm	Depend on final design
Cutting Model			Hydraulic cutting
Power source		Type	380V/3PH/50HZ	According to buyer request
		Main motor power(KW)	About 16	Depend on final design
		Total power(KW)	About 23	Depend on final design
Machinery dimension			See layout

Components for the Cold floor deck roll former machine

Name		Quantity	Technical Description
10 Tons Cantilever Type Electrical Automatic Decoiler (without coil car)		1 set	Structure: Arm-type Expanding model: hydraulic Releasing model: electrical With ultrasonic control
Main machine	Guiding device	1 set	With the Lubrication Device
	Roll forming system	1 set	Roller inner supporting structure: guide Colum
	Post cutting device	1 set	Cutting blade material: Cr12 quenched treatment
Supporting table		2pcs	Dimension: 2*2m
PLC control system		1 set	MITSUBISH, Frequency
Hydraulic station		1 set	.Famous Chinese brand

Packing and shipping about the Deck floor roll forming machine

More about our MAXMACH group

Product Tags: Cold Floor Deck Roll Forming Machine , Floor Deck Rollformer , Floor Deck Roll Machine
