Factory Supply Program Controlled Automatic Dewatering Press Filter Price

Factory supply program controlled automatic dewatering press filter price

Factory supply program controlled automatic dewatering press filter price

Structure and operating principle

1. Filter press consist of frame ,filter plate ,pressing system(manual , mechanical or hydraulic ) and electric control cabinet .
2. Frame consists of base , push plate and girder and supports the pressing device and filter plates .
3. Filter plates are installed on girder between tail plate and push plate , with filter cloth sandwiched in them.
4. In operation , the pressing device(cylinder piston rod or screw ) drives the push plate to press the filter plates and filter cloth between push plate and tail plate . Filter chambers are formed between pressed filter plates and material get in to The filter chambers through the feeding port in tail plate . Solid particles are trapped in filter chambers form into cakes , while liquid is discharged out of the tail Plate . In similar manner ,to drying the press cakes , compressed air can be introduced through the washing port .
5. Plate and frame type filter-Press is the same as recessed plate filter press in structure ,except the filtering part that consists of one plate , one frame and filter cloth ,with filter chamber between plate and frame.
6. Liquid stream of filter press can be divided into exeternal stream and internal stream . exeternal streamrefers to that the filtrate is discharged directly from outlet port of filter plate; internal stream refers to that the filtrate from various filter plate is collected before being discharged out of the filtrate port .

 Design feature of press filter:

Automatic chamber/recessed  filter press use micro computer processor, PLC and touch screen to control every part's actions, such as: cylinder, plate shifter, cloth washing etc.) and remote control ports are left.

High efficiency filter press expended the length of cylinder and can discharge several cakes every time. The advantages: stable performance, high efficiency 3-6 times and lower running cost.

The fast open system can increase the cale discharging efficiency 3-6 times,especially for the filter press that have a large quantity of plates and need frequent operations.

Technical data of press filtering machine  by auto dwelling :

Industrial art  specification :

Hydraulic station used in press filter:

Electric control box in press filter:

Filter plate in press filter:

 Filter plate pressure detection :

Our workshop of press filter:

Press filter worksite :

Trade assurance advantages:

1. Quickly lock trusted seller, saving time and energy;
2. Reduce the risk of online purchasing;
3. If there is a trade disputes, you can complain to Alibaba and get benefits compensation.

We are a member of trade assurance on Alibaba, and our trade assurance amount is USD72000.00 Through trade assurance you can 100% payment refund up to trade assurance amount for orders not meeting agreed Delivery or Quality terms.

Our Cetification of press filter:

In order to supply a more suitable filter press for you, please make us clear about your requirements:

What’s the material to filter?

What’s the solid content (%)?

What is the particle size?

What is the size of filter plate?

What is the filter pressure?

What is the filter output yield per hour?

What’s your local voltage? (customized for your requirement)

Is the liquid corrosive?

Is the liquid hot?
