Painting Thickness Meter, Statistical Continuous Measurement, F/NF CT-115BS

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Port Shanghai
Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shanghai, China		Brand Name	Sunlight
Model Number	CT-115BS

Product Description

Painting Thickness Meter, Statistical Continuous Measurement, F/NF CT-115BS

Descriptions:

Statistical Type Coating Thickness Gauge CT-115 Series have two types: Type B ( Integral Type ), Type BS ( Separate Type ); can store 99 groups of the latest measurements; Integral Type suitable for single-hand operation, large probe with large contact surface have better stability, users can get continuous, good repetitive and precise measurements.

Separate Type can provide several type probe, measure can be more flexibility. It is a kind of portable measuring instrument, it can quickly, no damage and precise coating, coating thickness measurement; Not only can be used in the laboratory, also can be used in the engineering field; Through the use of different measuring head, but also can meet the needs of a variety of measurement; Widely used in manufacturing, metal processing industry, chemical industry, commodityinspection and testing field; Is the material protection professional. necessary instruments.

Specification:

Measuring Range	0~1250 um
Measuring Range	0~50mil (other range may be specified)
Resolution	0.1 um (0~99.9um)/1 um (over 100um)
Accuracy:	1~3%n or 2.5 um or 0.1mil (Whichever is the greater)
Minimum Measurement Area	6 mm
Minimal Surface	F Type conve*1.5 mm / concave 25 mm
Minimal Surface	NF Type conve*3 mm / concave 50mm
Datalogger	99groups measuring result
Operating Condition	Temp: 0~50°C /
Operating Condition	Humidity: <95%
Size	1407030 mm
Power Supply	2*1.5vAAA Um-4 Battery
Weight	130 g (Not including batteries)

Accessories:

Standard Accessories	Main Unit
	Calibration Foils
	Substrate ( Iron )
	Substrate ( Aluminium )
	Carrying Case
	Operation Manual
Optional Accessories	USB data output
Optional Accessories	Bluetooth data output
