TM-209 LUX-FC LED Light Meter
Description:
• According to JISC 1609 : 1993 and CNS 5119 general A class specifications
• Spectral response close to CIE Luminous spectral efficiency
• Measuring intensities of illumination in Lux or Foot-candle
• Sensor : Silicon photo diode and filter
• Cosine angular corrected
• Data hold
• 99 manual records
Application:
Checking LED Light Intensity
Specification:
Light Source Selecting |
Tungsten/Daylight, Fluorescent, 0~9 select rating |
Measuring range |
40, 400, 4,000, 40,000, 400,000 Lux, 40, 400, 4,000, 40,000, Foot-candle |
|
Accuracy
|
+/-3% (Calibrated to standard incandescent lamp 2856º K) and corrected LED day while-light spectrum. +/-6% (other visible light source) |
Meter size (LxWxH) |
130x55x38mm |
Sensor size (LxWxH) |
80x55x25mm |
Weight (including battery) |
250g |
