Home > Instruments & Meters > Test Instrument > Test Machine > New WF28 8mm Precise Colorimeter Color Different Meter CIELAB Display Mode DEL*a*b Formula
New WF28 8mm Precise Colorimeter Color Different Meter CIELAB Display Mode DEL*a*b Formula
US$ 950 - 1,200
MOQ: 1 Piece
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
WR10 Color Meter CIELAB WR10 8mm Digital Colorimeter Fast ShippingUS$ 350 - 450MOQ: 1 Piece -
New Portable WF32 16mm Colorimeter Color Difference Meter CIELAB CIELCH Display ModeUS$ 2,500 - 3,000MOQ: 1 Piece
-
WF30 4mm Digital Color Meter Colorimeter Display Mode CIELAB CIELCHUS$ 1,500 - 1,800MOQ: 1 Piece
-
New Portable WF30 16mm Colorimeter Color Meter CIELAB CIELCH Display Mode DEL*a*b FormulaUS$ 1,700 - 1,900MOQ: 1 Piece
-
WR18 Digital Color Meter Tester Measurement Interval 0.5 SecUS$ 750 - 1,050MOQ: 1 Piece
Model Number
WF28
Specifications
New WF28 8mm Precise Colorimeter Color Different Meter CIELAB Display Mode DEL*a*b Formula
Product Description
New WF28 8mm Precise Colorimeter Color Different Meter CIELAB Display Mode DEL*a*b Formula
1. The Colorimeter is aprofessional colorimeter designed and produced subject to the relevantstandards of International Commission on Illumination (CIE) and national stands.
2. Being with brand new imported key components,the instrument is well designed and features in precision, stability, easyhandling, easy to learn and cost-effective.
3. Theinstrument applies to the color quality control, color difference control,color difference analysis, sampling testing and online testing for industriesas textile, printing and dyeing, garments, shoes, leather, chemical, plastic,pigment, paint, ink, printing, metal, photography and toys etc., as well as to the auxiliary colormatching during the processes as injection, inking, painting and sprayingcoating etc.
| Model | WF28 |
| Display Mode | CIELAB, CIELCH |
| Color Difference Formula | E*ab |
| Illumination Condition | CIE Recommendation: 8/d |
| Light Source | LED Blue Excitation |
| Sensor | Photodiode Array |
| Measurement Condition |
Observer: CIE 10° Standard observer; Light source: D65; Contain light way: SCI SCE |
| Measurement Range | L: 0 to 100 |
| Repeated Accuracy | E<0.07(take the deviation average after 30 times measuring the whiteboard) |
| Table Difference | E<0.2 |
| Measurement Interval | 0.5 Sec. |
| Storage Capacity | Type sample data : 100 ; Testing sample data: 200 |
| Language Patterns | Simplified Chinese/English |
| Battery Charging Time | 8 hrs |
| Battery | Li-ion Battery, 5000Times Measurement |
| Lifetime of Bulb | 5Years More Than 1.6 Million Measurements |
| Display Screen | TFT True Color 2.8inch@(16:9) Resolution Ratio:400 x 240 |
| Interface of External | RS-232 (115200bps)- Connected with Micro Printer |
| Working Temperature Range | 0oC-40oC (32oF-104oF))(() |
| Storage Temperature Range | -20oC-50oC (-4oF-122oF)) |
| Humidity Range | Relative Humidity Less Than 85%,without Condensation |
| Weight | 700g |
| Size | 199 x 68 x 90 mm |
| Size of Exterior Package | 400 x 240 x340 mm |
| Standard Accessories | 3000mAH Li-ion Battery/AC Adapter/User Manual/Warranty Card |
| Optional Accessories | Flour Measuring Device/Liquid Measuring Device/Micro Printer |
