Advanced Double Beam UV Visible Spectromet U5200 8 Inches Touch Screen With Scanning Function

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

Model Number:

U5200

Size:

60*43*21cm

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Brand Name YK

Model Number U5200

Size 60*43*21cm

Weight 28kg

Focal Length 2nm

Wavelength Range 190-1100nm

Measurement Range 190-780nm

Advanced Double Beam UV Visible Spectromet U5200 8 Inches Touch Screen with Scanning Function

Features

1. Applied with 8 inch high resolution color LCD touch screen, friendly and easily to operate.

2. Excellent performance and outstanding stability

Fully enclosed monochromator and all optical mirror surfaces are coated with SiO2 protective film, to protect the optical parts from the effects of the gas and the environment.
Philips Tungsten lamp and Hamamatsu Deuterium lamp.
Adopt advanced guide screw structure, which ensures the wavelength accuracy and repeatability.
Advanced 32 bit microcontroller (NXP ds-lpc3250), which frequency can reach 533 MHz.
64 bit high performance AD from BB Company, USA.
32M storage capacity, supports Mouse operation and large capacity SD card.
Low Stray Light. The stray light is only 0.05%T which enables the users to decrease the analysis Relative Error greatly.

3. Easy to maintain

Unique socket design for tungsten lamp and deuterium lamp, free of optical debugging, equipment debugging an To avoid cross effect, Optical path and circuit are separated and cuts down on the maintenance expenses Therefore users no longer need to hire professionals to change or adjust lamps which greatly improves reliability
maintenance after replacing lamps. So there is no need for professional adjustment while replacing a new one.
