High Accuracy UV-Vis Scanning Spectrophotometer UV1800 Medical Laboratory Instrument
Introduction
The UV1800 is developed for precise testing with a stray light of only 0.05%T. The value is evident from the performance
provided everyday.
The local stand-alone software provides functions of basic mode, Quantitative Test and Kinetics.
Features
1. UV-Win software offers many operational and data processing capabilities and is supplied as standard with the UV1800.
2. Imported reputed brand Holographic Grating, 1200 lines/mm.
3. A number of optional accessories increase the flexibility of analysis.
4. Instrument Functions: Photometric, Quantitative, T, A, C.
5. LCD Graphic Screen, which can display Standard Curve.
6. Protected by software program Restore the instrument to normal work status in case of a power failure.
7. The RAM has the capability of saving 200 groups of data and 100 standard curves
Technical parameters:
Model |
UV1800 |
Optical System |
Ratio Double Beam, 1200L/mm Holographic Grating |
Wavelength |
190-1100nm |
Bandwidth |
1.8nm |
Wavelength Accuracy |
+/-0.3nm |
Wavelength Repeatability |
<=0.5nm |
Wavelength Set: |
Automatic |
Work Mode |
T, A, C |
Photometric Accuracy |
+/-0.3%T |
Stability |
+/-0.001A/H @500nm |
Stray Light |
<=0.05%T |
Baseline Flatness |
+/-0.002A |
Noise |
+/-0.001A |
Data Output |
USB |
Display Mode |
LCD Graphic Screen |
Detector: |
Silicon Photodiode |
Included Accessories
- 1 Main Instrument
- 1 Power Cable
- 4 pcs 10mm Glass Cuvettes
- 2 pcs 10mm Quartz Cuvettes
- 1 Cell Holder
- 1 Tungsten Lamp
- 1 Deuterium Lamp
- 1 Singal Cable
Optional Accessories
- 5mm-100mm Glass Cuvettes
- 5mm-100mm Quartz Cuvettes
- Tungsten Lamp
- Deuterium Lamp
- 50mm-100mm Cell Holder
- Professional Software
Overall Dimension & Weight
- Shipping Package Dimension: 520mm*450*320mm
- Gross Weight: 14kg
- Net Weight: 12kg
Applications
- Education in universities and colleges
- Environmental monitoring & control
- Food & Beverage production and quality control
- Agricultural monitoring
- Geology & metallurgy
- Gas & oil
