UV Visible Scanning Spectrophotometer UV1810 Split Beam Low Stray Light
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Graigar
Model Number:
UV1810
Size:
590*460*220mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High-accuracy and High-quality UV-Large-screen Scanning Spectrophotometer UV765/UV765(PC)NegotiableMOQ: 1 Piece -
UV1900 Double Beam UV-VIS Spectrophotometer 190-1100nm/2nmNegotiableMOQ: 1 Piece
-
Double-beam UV-Visible Spectrophotometer UV762 Wavelength Range190nm-1100nmNegotiableMOQ: 1 Piece
-
UV- Scanning Spectrophotometer UV756/756CRT USB InterfaceNegotiableMOQ: 1 Piece
-
UV Visible Spectrophotometer UV755B Split Beam Spectrometer 2nm BandwidthNegotiableMOQ: 1 Piece
Brand Name
Graigar
Model Number
UV1810
Size
590*460*220mm
Weight
25
Wavelength Range
190-1100nm
Measurement Range
190-780nm
UV Visible Scanning Spectrophotometer UV1810 Split Beam Low Stray Light
Features:
1. High performance variable spectral bandwidth 0.5/1/2/4/5/6nm (UV1810S).
2. USB interface with the PC.
3. Sample compartment design enables use of a wide range of optional accessories.
4. New ARM system, built-in dual languages(Chinese & English)operating system
5. Unique design of the optical system, high performance grating(1200lines/mm)
6. Socket design for Tungsten and Deuterium Lamp, free optical debugging after replacing.
7. 320*240 dot-matrix high lighting LCD, display scanning graph directly.
8. Optional carousel 8 positions cell holder.
Applications
- Pharmaceutical production and quality control;
- Bio-tech & life science;
- Environmental monitoring & control;
- Food & Beverage production and quality control;
- Agricultural monitoring;
- Clinical & forensic analysis;
- Geology & metallurgy;
- Gas & oil.
Included Accessories
- 1 Main Instrument
- 1 Power Cable
- 4 pcs 10mm Glass Cuvettes
- 2 pcs 10mm Quartz Cuvettes
- 1 Cell Holder
- 1 Tungsten Lamp (Imported)
- 1 Deuterium Lamp (Imported, 2000hours)
- 1 Singal Cable
- Professional software
Optional Accessories
- 5mm-100mm Glass Cuvettes
- 5mm-100mm Quartz Cuvettes
- Tungsten Lamp
- Deuterium Lamp
- 50mm-100mm Cell Holder
- Carousel 8 positions Cell Holder
Overall Dimension & Weight
- Shipping Package Dimension: 690mm*570*320mm(59*46*22cm)
- Gross Weight: 27kg
- Net Weight: 25kg
Technical Parameters:
| Model | UV1810 |
| Optical System | Split Beam, 1200Line/mm Grating |
| Wavelength Range | 190-1100nm |
| Spectral Bandwidth | 1.8nm |
| Wavelength Accuracy | +/-0.1nm (D2, 656.1nm); +/-0.3nm full range |
| Wavelength Repeatability | <=0.1nm |
| Wavelength Set | Automatically |
| Work Mode | T/A/C |
| Photometric Accuracy | +/-0.3%T |
| Stability | +/-0.0005A/h@500nm |
| Stray Light | <=0.05%T |
| Baseline Flatness | +/-0.001A |
| Noise | +/-0.0005A |
| Data Output | USB |
| Display Mode | LCD |
| Detector | Silicon Photodiode |
