Latest UV/Vis Scanning Spectrophotometer UV1700 Low Stray Light 0.05%T UV Visible Spectrophotometry
Features
1. High performance fixed 2nm spectral bandwidth.
2. Holographic blazed grating, 1200 lines/mm.
3. A number of optional accessories available which increase the flexibility of the analysis.
4. Functions: Photometric Measurement, Spectrum Scans, Quantitative Determination and DNA/Protein analysis.
5. Simple mechanical structure and modular electronics make routine maintenance very easy.
Technical parameters:
Model |
UV-755B |
UV1700 |
Optical System |
Ratio Double Beam, 1200L/mm Grating |
|
Wavelength |
200-1000nm |
190-1100nm |
Bandwidth |
2nm |
2nm |
Wavelength Accuracy |
+/-1nm |
+/-0.5nm |
Wavelength Repeatability |
<=0.5nm |
<=0.2nm |
Wavelength Set: |
Automatic |
Automatic |
Work Mode |
T, A, C |
T, A, C |
Photometric Accuracy |
+/-0.5%T |
+/-0.5%T |
Stability |
+/-0.002A/H @500nm |
+/-0.002A/H @500nm |
Stray Light |
<=0.2%T |
<=0.05%T |
Baseline Flatness |
+/-0.002A |
+/-0.001A |
Noise |
+/-0.001A |
+/-0.001A |
Data Output |
USB |
USB |
Display Mode |
LCD |
LCD |
Detector: |
Silicon Photodiode |
Silicon Photodiode |
Included Accessories
- 1 Main Instrument
- 1 Power Cable
- 4 pcs 10mm Glass Cuvettes
- 2 pcs 10mm Quartz Cuvettes
- 1 Cell Holder
- 1 Tungsten Lamp (Imported)
- 1 Deuterium Lamp (Imported, 2000 hours)
- 1 Singal Cable
- Profession Software based on windows
- Softdog
Optional Accessories
- 5mm-100mm Glass Cuvettes
- 5mm-100mm Quartz Cuvettes
- Tungsten Lamp
- Deuterium Lamp
- 50mm-100mm Cell Holder
Overall Dimension & Weight
- Shipping Package Dimension: 520mm*450*320mm
- Gross Weight: 14kg
- Net Weight: 12kg
Applications
- Education in universities and colleges
- Environmental monitoring & control
- Food & Beverage production and quality control
- Agricultural monitoring
- Geology & metallurgy
- Gas & oil
