U5100 Double Beam Scanning UV-Vis Spectrometer Low Stray Light Dual Lamp
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
YK
Model Number:
U5100
Size:
60*43*21cm
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
New Design U5000 Double Beam UV Vis Spectrometer Automatically High QualityNegotiableMOQ: 1 Piece -
Advanced Double Beam UV Visible Spectromet U5200 8 Inches Touch Screen With Scanning FunctionNegotiableMOQ: 1 Piece
-
High Accuracy UV-Vis Scanning Spectrophotometer UV1800 Medical Laboratory InstrumentNegotiableMOQ: 1 Piece
-
UV754 UV Visible Spectrophotometers Built-in Printer Single Beam UV/Vis SpectrometersNegotiableMOQ: 1 Piece
-
Latest UV/Vis Scanning Spectrophotometer UV1700 Low Stray Light 0.05%T UV Visible SpectrophotometryNegotiableMOQ: 1 Piece
Brand Name
YK
Model Number
U5100
Size
60*43*21cm
Weight
28 kg
Focal Length
1nm
Wavelength Range
190-1100nm
Measurement Range
190-780nm
U5100 Double Beam Scanning UV-Vis Spectrometer Low Stray Light Dual Lamp
Features
1. Applied with 8 inch high resolution color LCD touch screen, friendly and easily to operate.
2. Excellent performance and outstanding stability
- Fully enclosed monochromator and all optical mirror surfaces are coated with SiO2 protective film, to protect the optical parts from the effects of the gas and the environment.
- Philips Tungsten lamp and Hamamatsu Deuterium lamp.
- Adopt advanced guide screw structure, which ensures the wavelength accuracy and repeatability.
- Advanced 32 bit microcontroller (NXP ds-lpc3250), which frequency can reach 533 MHz.
- 64 bit high performance AD from BB Company, USA.
- 32M storage capacity, supports Mouse operation and large capacity SD card.
- Low Stray Light. The stray light is only 0.05%T which enables the users to decrease the analysis Relative Error greatly.
3. Easy to maintain
- Unique socket design for tungsten lamp and deuterium lamp, free of optical debugging, equipment debugging an To avoid cross effect, Optical path and circuit are separated and cuts down on the maintenance expenses Therefore users no longer need to hire professionals to change or adjust lamps which greatly improves reliability
- maintenance after replacing lamps. So there is no need for professional adjustment while replacing a new one.
Specifications
| Model | U5100 |
| Optical System | Double Beam, 1200Line/mm Grating |
| Wavelength Range | 190-1100nm |
| Spectral Bandwidth | 1nm |
| Wavelength Accuracy | +/-0.3nm |
| Wavelength Repeatability | <=0.1nm |
| Wavelength Set | Automatically |
| Work Mode | T/A/C/E |
| Photometric Accuracy | +/-0.002A(0-0.5A); +/-0.004A(0.5-1A); +/-0.2%T(0-100%T) |
| Stability | +/-0.0005A/h@500nm |
| Stray Light | <=0.03%T |
| Baseline Flatness | +/-0.0015A |
| Noise | - |
| Data Output | USB |
| Display Mode | 8"TFT |
| Detector | Silicon Photodiode |
Applications
- Pharmaceutical production and quality control;
- Bio-tech & life science;
- Environmental monitoring & control;
- Food & Beverage production and quality control;
- Agricultural monitoring;
- Clinical & forensic analysis;
- Geology & metallurgy;
- Gas & oil.
Included Accessories
- 1 Main Instrument
- 1 Power Cable
- 4 pcs 10mm Glass Cuvettes
- 2 pcs 10mm Quartz Cuvettes
- 1 Cell Holder
- 1 Tungsten Lamp
- 1 Deuterium Lamp
- 1 Singal Cable
- Professional software
Optional Accessories
- 5mm-100mm Glass Cuvettes
- 5mm-100mm Quartz Cuvettes
- Tungsten Lamp
- Deuterium Lamp
- 50mm-100mm Cell Holder
- Carousel 8 positions Cell Holder
