OK-027 Pressure-sensitive Adhesive Stick Labeling Machine

     pressure-sensitive adhesive stick Labeling machine

   Technique parameter:

 Inner diameter of label: 76mm

 Max outer diameter of label: 300mm

 Label width: 10-200mm

 Label length: 10-400mm

 Label precision: ±1mm

 Production capacity: 20-200 bottle/min(different bottle and label size,different speed)

 Power: 250W 220V 50Hz (according to the customer’s requirement)

 Weight: 200Kg

 Dimension:1500mm×950mm×1260mm(L×W×H)

   Functions:

 This machine is used for using the Taiwan touching type of PLC control or knob control. It is made up of photoelectricity equipment of Japan OMRON. Synchronization electrical,timing electrical, conveyer belt. Import strap etc correlative part.

 The design of mainframe part absorbed label transmit of import machine and solved the unsteady ingredient of homemade common label.

 The machine is suitable for various specifications of bottles. Its operation is easy and it can be finished in a short time.

 The quick printer adopts the motor drive, gas drive. The words in the ribbon are clear and clean.

 The whole machine is designed to meet GMP standard.

 This machine is suitable for processing the big round label of medicine, chemical, food, commodity etc.

Shanghai OK machinery Co., Ltd. was established in 2000, It's a professional manufacturer of liquid food and beverage equipment.

 We have good experience especially in filling and capping technology and they provide customized service and turnkey project.

The products scope as below:

PET bottle filling machine,

As : PET bottle water , PET bottle juice , PET bottle cola , PET bottle wine oil .....

Glass bottle  filling machine,

As : glass bottle beer , glass bottle cola , glass bottle juice

Capping machine,

Pet cap , metal cap , crown cap

Bottle washing machine,

Water treatment system

Oil filling machine/piston filler,

Other bottle filling machine,

beer filling machine , beer filler , beer equipment

Labeling machine,

Film shrinking wrap packing/package machine,

Bottle unscrambler,and some drinks production line auxiliary.
