Cu/Al LV/ MV Three-Core XLPE Electrical Power Cable With PVC Outer Sheath

Cu/Al LV/MV Three-Core XLPE Electrical Power Cable with PVC Outer Sheath

Advantages:

--Factory Direct Supply of low voltage, medium voltage and high voltage power cable with armor or without armor,

--OEM Service Provided,

--Best Cable Quality, Premium Service,

--All for Customers!

Cu/Al LV/MV Three-Core XLPE Cable with PVC Outer Sheath

1. Application for Cu/Al LV/MV Three-Core XLPE Cable with PVC Outer Sheath:

It is used as power and connecting cables in mechanical engineering for tooling machinery, control unit, production lines.

2. Performance Characteristics for Cu/Al LV/MV Three-Core XLPE Cable with PVC Outer Sheath:

1).The long-time working temperature of conductor of PVC insulated control cable is 70°C.

The long-time working temperature of conductor of XLPE insulated control cable is 90°C.

2).During short circuit(max permanent time is not more than 5 seconds),the max temperature of cable conductor is not more than 160C.

3).Ambient temperature is not lower than 0 °C.

4).it's minium bending when cable is installed.

Unarmored 6D(D=overall diameter)

Armored or copper-tape screened 12D(D=overall diameter)

Shielded flexile cable 6D(D=overall diameter)

3.  Types and descriptions for Cu/Al LV/MV Three-Core XLPE Cable with PVC Outer Sheath:

4. Picture Showcase for Cu/Al LV/MV Three-Core XLPE Cable with PVC Outer Sheath:

5.Main Features for Cu/Al LV/MV Three-Core XLPE Cable with PVC Outer Sheath:

Operating temperature
Max. Permissible continuous operating temperature of Conductors shall not exceed 70℃
Conductor Short circuit temperature
Not exceeding 160℃ .( Max. duration 5 seconds)
Bending radius:
Bending radius of single core cable: 20D
Bending radius multi-core cable: 15D
D=Actual overall diameter of cable (mm)
Installation temperature:
The lowest temperature of installation is 0℃ .
Laying conditions and basic parameters for calculating current ratings:
Method of laying  Ambient temperature
In air  40℃
Direct burial  25℃
Soil thermal resistivity 1.0℃·m/W
Layout of single core cables: In triangle (Touch each other)

Quality Assurance:

With Yiteng, all cables are produced by strict inspection and testing:

1). Raw Material: Copper, Aluminium, PVC, PE and XLPE granules and all other materials for producing cables are all inspected carefully automatically. Only the qualified will be applied into cable production, the disqualified will be rejected.

2). Production Procedure: Cables in Yiteng are produced by advanced cable production machines.

3). Testing: Cables in Yiteng will not be packed until they are tested totally qualified. Cable Testing Machines includes Online Core Shift Detection Device, Tension Tester, Aging Test Chamber, Experimental Apparatus of Combustion, Insulation Resistance Tester and etc…

Yiteng Cable’s business philosophy is and always remains “Helping Customers to Succeed”. We commit ourselves and our resources to the development of the cable industry by establishing strategic cooperation with global agents and customers.

All for Customers—More Than A Promise

Apart from supplying good quality cables, our service teams are always ready to provide expertise to customers.

Yiteng Cable Technology Hebei Co.,Ltd. is a specialized manufacturer of cables, including:

Δ Aluminum Alloy Cable with or without Armor and Interlock,

Δ Control Cable with Multi-Cores,

Δ Computer Cable with Individual and General Shileding and PE/ PVC/ XLPE Insulation,

Δ Shielded Cable or Screened Cable,

Δ ABC Cable in Aluminum for Overhead Application,

Δ Power Cable with PE/PVC/XLPE Insulation and PVC Sheath and Armor,

Δ Rubber Cable for General Purposes, Welding Machines or for Mining,

Δ Armored Cable with Steel Tape or Steel Wire Armor,

Δ PVC Cable with PVC Insulation and PVC Sheath,

Δ Low Voltage Power Cable,

Δ Medium Voltage Power Cable,

Δ Fire Resistant Cable and Flame Retardant Cable,

Δ Mining Cable, Flexible Rubber Mining Cable, PVC and XLPE Insulated Power Mining Cable,

Δ High Temperature Cable, including silicone rubber insulated cable and Teflon insulated cable,

Besides, Yiteng Cable also produce cables of customers' special requirement.

These cables can be used for power transmission in air, underground or industrial, such as power station, coal, railway, agriculture and estate, etc...
