Medium Voltage MV Below 35KV XLPE Insulated Power Cable
--Yiteng Cable-- a Specialized Cable Manufacturer for 20 Years!
--Factory Direct Supply of low voltage, medium voltage and high voltage power cable with armor or without armor,
--OEM Service Provided,
--Best Cable Quality, Premium Service,
Product Description
Medium Voltage Below 35kv XLPE Insulated Power Cable
|
XLPE Power Cable Type |
No . of cores |
Rated voltage(KV) of XLPE Power Cable | ||||
| 0.6/1 | 1.8/3 | 3.6/6 | 6/6 6/10 |
8.7/10 8.7/15 |
||
| Nominal area of conductor (mm2) | ||||||
|
YJV YJLV YJV22 YJLV22 YJV32 YJLV32 |
1,2,3, 3+1, 3+2, 4+1, 5 |
1.5-630 | 10-400 | 25-400 | 25-400 | 25-400 |
|
XLPE Power Cable Type |
Description for XLPE Insulated PVC Sheathed Power Cable | Main application for XLPE Insulated PVC Sheathed Power Cable |
|
YJV YJLV |
Cu or AL conductor XLPE insulated PVC Sheath Power cable |
For laying indoor and outdoor, unable to bear certain extermal mechanical force but the tractive force during laying. Laying Single core cable in magnetic duct is not permissble |
| YJV22 YJLV22 |
Cu or AL conductor XLPE insulated steel tape armored PVC sheathed power cable |
For laying underground, bear external mechanical force, but unable to bear large pulling force |
| YJV32 YJLV32 |
Cu or AL conductor XLPE insulated thin steel wire armoured PVC sheathed power cable |
For laying under ground, vertical well, or underwater, able to bear certain pulling force. |
1. Manufacturing Standards for Medium Voltage MV Below 35KV XLPE Insulated Power Cable:
This kind of XLPE Insulated PVC Sheathed Medium Voltage Below 35KV Power Cable is manufacturerd in accordance with ASTM ICEA BS DIN IEC GB AS/NZS etc..
2. Operating Features for Medium Voltage MV Below 35KV XLPE Insulated Power Cable:
1). Operating temperature for XLPE Power Cable:
Max. Permissible continuous operating temperature of Conductors shall not exceed 90℃
Conductor Short circuit temperature
Not exceeding 250℃ . (Max. Duration 5 seconds)
2). Bending radius for XLPE Power Cable:
Bending radius of single core cable:20D
Bending radius of multi-core cable: 15D
D=Actual overall diameter of cable (mm)
3). Installation temperature for XLPE Power Cable:
The lowest temperature of installation is 0 ℃.
Laying conditions and basic parameters for calculating current ratings:
Method of laying Ambient temperature
In air 40℃
Direct burial 25℃
Soil thermal resistivity 1.0℃· m/W
Layout of single core cables: In parallel
(Spacing side by side: 1D D=overall diameter)
4. Picture Showcase of Medium Voltage Below 35KV XLPE Insulated Power Cable:
Quality Assurance:
With Yiteng, all cables are produced by strict inspection and testing:
1). Raw Material: Copper, Aluminium, PVC, PE and XLPE granules and all other materials for producing cables are all inspected carefully automatically. Only the qualified will be applied into cable production, the disqualified will be rejected.
2). Production Procedure: Cables in Yiteng are produced by advanced cable production machines.
3). Testing: Cables in Yiteng will not be packed until they are tested totally qualified. Cable Testing Machines includes Online Core Shift Detection Device, Tension Tester, Aging Test Chamber, Experimental Apparatus of Combustion, Insulation Resistance Tester and etc…
4). Package and Shippment:
With Yiteng Cable,
1. Cables are packed in standard export drums or other ways per customer's requirement;
2. Cables are handled and shipped carefully to ensure perfect package upon customer's receiving.
Service Commitment-Why Choose US?
Yiteng Cable Technology Hebei Co., Ltd. sincerely ensure every present and potential customers and friends that we will always:
1. Make A Response with 12 Hours to All Custoemers;
2. ISO9001, ISO14001, CCC Certificates for Factory and Cable Products;
3. Factory Direct Supply and OEM Service of Cable Products;
4. Yiteng Cable will not only serve goods before selling, but will be better and better during sales and after sales;
5. All Customers' Information will be kept confidential without permission.
Company Profile:
Yiteng Cable Technology Hebei Co.,Ltd. is a specialized manufacturer of cables, including:
Δ Aluminum Alloy Cable with or without Armor and Interlock,
Δ Control Cable with Multi-Cores,
Δ Computer Cable with Individual and General Shileding and PE/ PVC/ XLPE Insulation,
Δ Shielded Cable or Screened Cable,
Δ ABC Cable in Aluminum for Overhead Application,
Δ Power Cable with PE/PVC/XLPE Insulation and PVC Sheath and Armor,
Δ Rubber Cable for General Purposes, Welding Machines or for Mining,
Δ Armored Cable with Steel Tape or Steel Wire Armor,
Δ PVC Cable with PVC Insulation and PVC Sheath,
Δ Low Voltage Power Cable,
Δ Medium Voltage Power Cable,
Δ Fire Resistant Cable and Flame Retardant Cable,
Δ Mining Cable, Flexible Rubber Mining Cable, PVC and XLPE Insulated Power Mining Cable,
Δ High Temperature Cable, including silicone rubber insulated cable and Teflon insulated cable,
Besides, Yiteng Cable also produce cables of customers' special requirement.
These cables can be used for power transmission in air, underground or industrial, such as power station, coal, railway, agriculture and estate, etc...
Questions and Answers!
Experts of Yiteng Cable will always wait to answer all your questions!
1. When was Yiteng Cable founded?
Our factory was first establlished in Year 1994 and then it changed names several times.
2. What kinds of cables does Yiteng Cable produce?
1). Overhead Line Cables:
Bare Conductor: AAC, AAAC, ACAR, ACSR, etc
ABC Cable( Aerial Bundle Cable): Solid Core, Duplex, Triplex, Quadruplex Service Drop, etc;
2). Alluminum Alloy Cable;
3). Shield Cable;
4). Control Cable;
5). Power Cable;
6). Special Cable in accordance with Customer's specific requirement.
3. What certificates does Yiteng Cable has been approved?
Yiteng Cable has been approved successfully by CCC, ISO9001 and ISO14001, SGS, etc;
4. What's the Minimum Order Quantity?
Yiteng Cable accepts small trial orders to facilitate customer's inspection and trial of our cable.
5. Can customers audit Yiteng Cable?
Sure, Yiteng Cable alwlays welcome customers, home and aborad, come and audit the factory before cooperation. Cables in Yiteng can also be inspected by customers personally or the third party every time before shippment.
