Flexographic Printing Machine for Dual-Sided Printability pp woven fabric printing machine
Our Machine Approved by ISO9001, 2000 and European CE standard.
Use:
Flexographic Printing Machine for Dual-Sided Printability pp woven fabric printing machine is suitable for printing various packing materials, such as polyethylene, polyethylene plastic bag, glass paper, roll paper, etc. It is an ideal printing equiment fr producing paper packing bag, shopping handbag, vest bag and cloths bag, etc.
Characteristics:
1. Easy operation, flexible starting, accurate colour register.
2. Flexographic Printing Machine for Dual-Sided Printability is with auto meter counter. Working length can be preset. Machine will stop automatically when reached the preset length or material is cut off.
3. Lift and lower the printing plate cylinder manually, it will automatically stir the printing ink after lifting.
4. The printing ink is spread by the knurled cylinder with even ink colour.
5. Reliable drying system coordinated with high speed rotation.
6.360 degree continuous and adjustable longitudinal register device.
7. Flexographic Printing Machine for Dual-Sided Printability is with imported frequency inverter motor to adjust the printing speed.
8. There are inching/stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.
Main Technical Parameters
Machine Model |
YT-2600 |
YT-2800 |
YT-21000 |
Max. Roll Width |
600mm |
800mm |
1000mm |
Max. Printing |
560mm |
760mm |
960mm |
Printing Length (mm) |
180-1200 |
180-1200 |
180-1200 |
Max. Roll Diameter |
Φ 450mm |
Φ 450mm |
Φ 450mm |
Printing Speed |
5-50m/min |
5-50m/min |
5-50m/min |
Plate Thickness(Including |
2.38mm |
2.38mm |
2.38mm |
Power |
10.87kw |
12.5kw |
14.37kw |
Weight |
3000kg |
3500kg |
4000kg |
OverallDimension(L*W*H) |
2200X1600X2400mm |
2200X1800X2400mm |
2200X2000X2400mm |
Our working factory:
More details, pls feel free to contact.
