Home > Products > Printing Machine > China Economical Small Digital Plastic Bag Printing Machine
China Economical Small Digital Plastic Bag Printing Machine
- Ningbo/Shanghai
- T/T Money Gram Credit Card
You May Like
Product Details
| Condition | New | Plate Type | Letterpress | |
| Place of Origin | Zhejiang, China | Brand Name | JINGDIANRUIHUA | |
| Model Number | YT-2600 | Usage | Card Printer, Label Printer, Paper Printer, Other, Card Printer, Label Printer, Paper Printer, PE,OPP,BOPP,PET Film Printer, Non Woven Printer, Woven Bag Printer | |
| Automatic Grade | Semi-Automatic | Voltage | 380V 50Hz, 3Phase 4Line 380V 50Hz | |
| Gross Power | 11kw | Dimensions(L*W*H) | 2100*2000*2200mm | |
| Weight | 2000KGS | Certification | CE&ISO | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
China Economical Small Digital Plastic Bag Printing Machine
Our Machine Approved by ISO9001, 2000 and European CE standard.
Use:
China Economical Small Digital Plastic Bag Printing Machine is used for printing various packing materials, such as polyethylene, polyethylene plastic bag, glass paper, roll paper, etc. It is an ideal printing equiment fr producing paper packing bag, shopping handbag, vest bag and cloths bag, etc.
Characteristics:
1. Easy operation, flexible starting, accurate colour register.
2. China Economical Small Digital Plastic Bag Printing Machine is with auto meter counter. Working length can be preset. Machine will stop automatically when reached the preset length or material is cut off.
3. Lift and lower the printing plate cylinder manually, it will automatically stir the printing ink after lifting.
4. The printing ink is spread by the knurled cylinder with even ink colour.
5. Reliable drying system coordinated with high speed rotation.
6.360 degree continuous and adjustable longitudinal register device.
7. China Economical Small Digital Plastic Bag Printing Machine is with imported frequency inverter motor to adjust the printing speed.
8. There are inching/stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.
Main Technical Parameters | |||
Machine Model | YT-2600 | YT-2800 | YT-21000 |
Max. Roll Width | 600mm | 800mm | 1000mm |
Max. Printing | 560mm | 760mm | 960mm |
Printing Length (mm) | 180-1200 | 180-1200 | 180-1200 |
Max. Roll Diameter | Φ 450mm | Φ 450mm | Φ 450mm |
Printing Speed | 5-50m/min | 5-50m/min | 5-50m/min |
Plate Thickness(Including | 2.38mm | 2.38mm | 2.38mm |
Power | 10.87kw | 12.5kw | 14.37kw |
Weight | 3000kg | 3500kg | 4000kg |
OverallDimension(L*W*H) | 2200X1600X2400mm | 2200X1800X2400mm | 2200X2000X2400mm |
Our factory:
More details, pls feel free to contact.
