Multicolor printing machine from wenzhou
Use:
Adhestive Label and Paper Flexo Printing Machine is suitable for printing such packing materials as polyethylene, polypropylene plastic bag, glass paper and roll paper, etc. And it is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.
Characteristics:
1. Easy operation, flexible starting, accurate colour register.
2. The meter counter can set printing quantity according to the requirements. Stop the machine automatically at the set quantity or when the material is cut off.
3. Lift and lower the printing plate cylinder manually, it will automatically stir the printing ink after lifting.
4. The printing ink is spread by the knurled cylinder with even ink colour.
5. Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.
6.3600 continuous and adjustable longitudinal register device.
7. The imported frequency control of motor speed adapts to different printing speeds.
8. There are inching/stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.
|
Main Technical Variables: | |||
Model of Machine |
YT-6600 |
YT-6800 |
YT-61000 |
Max. Width of PrintingMaterial |
600mm |
800mm |
1000mm |
Max. Printing |
560mm |
760mm |
960mm |
Length Range |
191-990 |
191-990 |
191-990 |
Max. Diameter of Roll Material |
Φ 450mm |
Φ 450mm |
Φ 450mm |
Printing Speed |
5-80m/min |
5-80m/min |
5-80m/min |
Thickness of |
2.38mm |
2.38mm |
2.38mm |
Total Power |
22kw |
28kw |
32kw |
Weight of |
3000kg |
3500kg |
4000kg |
Overall(mm)Dimensions |
6800X1600X2400 |
6800X1800X2400 |
6800X2000X2400 |
1. Machine customize is available |
2. 24 hours online service |
3. After sales service: engineers are available to service overseas. If you required, we will send our technician, and the forward-return tickets, food, hotel, and salary of USD70 per day would be paid by customer side. |
4. In the warranty time, we will provide free parts replacements and maintenance service. |
5. Our machine is with whole life technical support. And out of warranty time, any question, we will provide solutions ASAP. |
Q: Are you a factory or trading company? |
A: We are manufacturer, have our own factory with over 15 years experiences. From us, you not only get machines, also the best solutions. |
Q: What kind of quality certificate do you have? |
A: We have CE certificate, SGS, ISO, etc. |
Q: How does your factory do regarding quality control? |
A: Quality is our focus. From the beginning till the end of machine manufacture, we inspect every component before using. Machine will have tests after finished. |
Q: How about the delivery time? |
A: Usually, our machines can be delivered within 30 working days. |
Q: What’s the payment terms? |
A: Usually, we do T/T with 30% deposit, and 70% balance paid before machine delivery. And L/C, western union, etc. are also acceptable. |
Q:Where is your factory located? How can I visit? |
A: We are in Ruian City, Zhejiang Province, China. About one hour from Shanghai by air. All our clients, from home and abroad, are warmly welcome to visit us! |
