plc control paper cup printing machine price

FOB Price

USD $5,500 - $45,000 / Set

1 Set(Min.Order)

Supply Ability 50 Set / Sets per Month
Port Ningbo / Shanghai
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Plate Type:	Letterpress	Place of Origin:	Zhejiang, China
Brand Name:	JINGDIANRUIHUA	Model Number:	GAYT-6600/6800/62000	Usage:	Paper Printer, Other, Paper Printer, paper pe film pp film printing machine
Automatic Grade:	Automatic	Voltage:	380V/220V440	Gross Power:	58kw
Dimensions(LWH):	4.8m3.2m2.8m	Weight:	6300kg	Certification:	CE/SGS
After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

cup printing machine

Detailed Product Description

-Main Technical Parameter:

1. Low speed and full load startup; stable running by tension control when increasing and decreasing speed, noise is decreased

2. High dots presentation rate under high speed; clear and vivid stratification of screen printing; strong stereo effect and accurate registering

3. Aluminum roller adopts the Japan semi-sealing small bearing; flinty oxidation, static and dynamic balancing treatments are conducted; low resistance and small flop.

4. The special made modulus angular gears adopted printing size and full printing specifications (5mm is spec)

5. With the air exhaust, blowing and heating settings; the heating system adopts the central thermostatic control system and group management, also with the cold air forming devices

6. Printing rolls should keep moving while machine halted

7. Material holder use air shaft

8. Auto tension control

9. Unwind with auto deviation correction system (EPC)

10. EDGE position control

11. Reversible printing 6 color press for 6+0,1+5,2+4,3+3

12.1 set of printing cylinder, size 15 inches

printing width Item	600mm	800mm	1000mm	1200mm	1400mm	1600mm	1800mm	2000mm
Printing color	6(PC:6+0,4+2,5+1,3+3)
Printing length	7.5”-40”/7.5”-50
Printing plate lifting system	Hydraulic press control
Menchanical speed	140m/min
Printing speed	80m-120/min
Anilox cylinder	Ceramic anilox roller
Register precision	Longitude:±0.20mm,Transverse±0.20mm
Rewinder/UnwinderDIA	φ600mm
Master motor	3.7kw	3.7kw	5.5kw	5.5kw	7.5kw	7.5kw	11kw	11kw
Unwinder motor	1.1kw		1.5kw		2.2kw		3.0kw
Rewinder motor	1.5kw		2.2kw		3.0kw		3.7kw
Electrical heater	14kw	16kw	20kw	22kw	24kw	26kw	28kw	30kkw
Blower of heater	1.5kw*2	1.1kw*3	1.1kw*3	1.1kw*3	1.5kw*3	1.5kw*3	2.2kw*3	2.2kw*3
Blower of nature wind	0.75kw	0.75kw	1.1kw	1.1kw	1.1kw	1.5kw	1.5kw	1.5kw
Inking motor	370w	750w	750w	750w	750w	750w	750w	750w
Master frequency converter	(Panasonic)/ (Toshiba)transducer Japan
Bearing	Japan(NSK)
Unilateral bearing	ASNU(Germany)
Weight	4500kg	4750kg	5000kg	5250kg	5500kg	5750kg	6000kg	6300kg
Master Power	25k	27kw	34kw	37kw	43kw	47kw	55kw	58kw
Dimension(LWH)	4.8m* 1.8m* 2.8m	4.8m* 2.0m* 2.8m	4.8m* 2.2m* 2.8m	4.8m* 2.4m* 2.8m	4.8m* 2.6m* 2.8m	4.8m* 2.8m* 2.8m	4.8m* 3.0m* 2.8m	4.8m* 3.2m* 2.8m

COMPUTER CONTROL COLOR REGISTRATION SYSTEM:

HYDRAULIC PRESSURE SYSTEM FOR JUMBO MATERIAL:

system

exhibition

Packaging & Shipping

We use stout wood cases to pack the machines which can ensure the safety of products in the transportation.We can also pack the products as customers requests

packing 1 shipping

Our Services

1.Installation Services

Installation Services are available with all new machine purchases. We will provide the technical know-how for your operation smooth transition and support for installing, debugging, operation of the machine, it will indicate you how to use this machine well.

2.Clients Traning Services

We can train your staff to use your film blowing equipment systems properly.It means that we offer Customers Training, teaching how to use the systems most efficiently and safely as well as how to maintain optimal operational productivity.

3.After Sales Service

We offer the Preventative Maintenance and After Sales Service. For we strongly feels about the importance of supporting our customers and the product solutions we provide.Consequently we offer comprehensive maintenance options to prevent equipment issues before they become problems. Also we offer one year guarantee period.

In one words,your satisfication is our persuit forever!

FAQ

Understand your needs
Individual machine is designed upon user’s need
In-time service
On-line / overseas technical support
Fast delivery
Always here for your service
