Solid Float Oil Boom For Containing Oil In a Spill
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | JXY | |
| Model Number | JXYWGV |
Product Description
Specifications
The solid float PVC boom is an economical, universal boom for intercepting oil spill and other floats on waters.Solid Float Oil Boom For Containing Oil In a Spill
The Solid Float Oil Boom is the oldest method of combating oil spills on water. It consists of a floating buoy, to which a skirt made of absorbent material is attached. The skirt contains the oil and the buoy takes care of the flotation.
Solid Float Oil Boom is a fast response barrier designed for immediate deployment around spills. Equipped for calm water, fast water, or moving water areas, these booms can effectively contain your spills and prevent spreading around your site.
Oil Containment Booms are used for many purposes
Containment, concentration & recovery of oil
After a spill, ocean waves and currents cause oil to spread quickly, dispersing it so that the surface layer of oil is thin and
patchy. A properly deployed oil containment boom keeps the oil contained and concentrates it into thicker surface layers so
that skimmers, vacuums, or other collection methods can be used more effectively.
Diverting oil to a collection area
In situations where the oil-contaminated water is moving, a well-placed oil containment boom can divert the flow of the oil
and direct it into a collection area.
Protection of important or sensitive places
If an oil spill is too dispersed to be completely contained, containment booms can be placed around important or sensitive
areas to keep oil out.
Model | JXY- WGV | JXY- WGV | JXY- WGV | JXY- WGV | JXY- WGV | JXY- WGV | JXY- WGV | JXY- WGV |
Overall Height(mm) | 600 | 700 | 750 | 800 | 900 | 1000 | 1100 | 1500 |
Freeboard | 200 | 230 | 250 | 250 | 280 | 300 | 300 | 350 |
Draft | 400 | 470 | 500 | 500 | 620 | 700 | 800 | 1150 |
Length Per | 15/20/25/30 | |||||||
Max, working Tensile Strength (KN)
|
20 |
25 |
30 |
45 |
55 |
75 |
85 |
130 |
Max, wave Height to withstand (m) |
0.5 |
0.5 |
1 |
1.5 |
1.8 |
2 |
2 |
3 |
Max, wind Speed to Withstand (m/s) |
8 |
10 |
10 |
15 |
15 |
18 |
20 |
20 |
Max, current Speed to Withstand (Kn) |
1 |
1
|
1.5 |
1.5 |
2 |
2.5 |
2.5 |
3 |
Packing dimensions for 20m | 1*1*0.6 | 1.2*1*1 | 1.2*1*1 | 1.3*1.1 *1.1 | 1.4*1.5 | 1.4*1.6 | 1.4*1.7 *1.4 | 1.6*1.9 *1.8 |
Note: The technical data are subject to change without notice due to modifications to the product and shall be confirmed by the manufacture and the customer.
Jxy- We provide the best solutions for Oil Spill Containment.
At JXY we have a wealth of knowledge in spill control products and services.
Our hugely experienced team really do make all the difference. It’s a team that’s growing too, as we become recognised as a major player in the spill control industry. Whether it's advice over the phone or email, you can be sure of one thing, we know spill care inside and out.
Let us help your business or organisation avoid the pitfalls that can lead to expensive fines, bad publicity or the detrimental aftermath of a toxic or harmful spill.
