XK6325 CNC MILLING MACHINE

Name: XK6325 CNC MILLING MACHINE
Brand: HELI
SKU: 103161257

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

HELI

Tengzhou Runfa Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name HELI

Model Number XK6325

Type Vertical

CNC or Not CNC

Voltage 380V

Power(W) 3HP

Dimension(L*W*H) 1900*2000*2230

Weight 1500KG

Certification ISO 9001

Warranty 12 months

After-sales Service Provided No overseas service provided

Specifications

economic and high precision

This milling machine equipped with economic CNC system is three coordinate NC milling machine possessing

a widely universal performance and attachments in a great varity may perform procedures, such as milling,

boring and drilling etc in addition it may be applied for processing various kinds of jobs without jigs such as

cams profile boards and jigs with complex figuration etc.

Model				Unit	XK6325
Table size				mm	254*1270
					254*1370
T slot					3*16
Table loading				kg	280
X axis (table longitudinal move) travel				mm	750
					850
Y axis (table cross move) travel				mm	400
Z axis (Quill move) travel				mm	127
X/Y/Z axis rapid feed				mm/min	5000
X/Y/Z axis servo motor				kw	1
Knee vertical travel				mm	400
Ram travel				mm	465
Distance from spindle to table				mm	0-400
Milling head	Spindle speed	Standard:16steps		rpm	50HZ:60-4500/60HZ:80-5440
		Optional: Variable			65-4200
	Spindle taper				Standard:R8/Optional:ISO40
	Motor Power			HP	3
	Head rotating		Swiveling		90°
			Tilting		90°
CNC					KND/HD500/GSK
Package size				cm	190200223
G.W.				kg	1500
