Home > Manufacturing & Processing Machinery > Machine Tools > Milling Machine > MC 4 CNC MILLING MACHINE
MC 4 CNC MILLING MACHINE
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
HELI
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Place of Origin
Shandong, China
Brand Name
HELI
Model Number
MC 4
Type
Vertical
CNC or Not
CNC
Voltage
380V/440V
Power(W)
2.2KW
Dimension(L*W*H)
1600 x 1600 x 2200
Weight
1300KG
Certification
ISO 9001-2008
Warranty
12 months
After-sales Service Provided
No overseas service provided
Specifications
1.hardened worktable and guideway2.high speed spindle and high precision
3.stable machine body and durable
4.more efficient
Constructive Key Features:
Bus with hardened and ground guides WIDER
Gears built especially steel hardened and ground
especially hardened and ground steel guideway, supported on precision bearings
Item Name |
Unit |
Model:MC 4 |
worktable |
mm |
1200 x 280 |
T-Slot |
|
14/5 |
X,Y,Z axis travel |
mm |
700 x 350 x400 |
Z axis spindle travel |
mm |
100 |
Spindle speed |
r.p.m |
5440 |
Main Motor power |
kw |
2. two speed |
Spindle taper |
|
BT30(R8) |
Distance from spindle center to column |
mm |
100--550 |
Distance from spindle nose to worktable |
mm |
0--400 |
X,Y axis Servo motor |
N.m |
6 |
Z axis Servo motor |
N.m |
4 |
Positioning accuracy |
mm |
0.03 |
Repeatability positioning accuracy |
mm |
0.02 |
Machine weight |
Kg |
1300 |
Overall size |
mm |
1600 x 1600 x 2200 |
