Small CNC MILLING MACHINE XK7124
US$ 8,000 - 11,800
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
HELI
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO/SHANGHAI/DA LIAN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Place of Origin
Shandong, China
Brand Name
HELI
Model Number
XK7124
Type
Vertical
CNC or Not
CNC
Voltage
380V
Power(W)
2.2KW
Dimension(L*W*H)
1300 x 1400 x 2000
Weight
900KG
Certification
ISO 9001
Warranty
12 months
After-sales Service Provided
No overseas service provided
Specifications
1.stable structure and high rigidity2.small machine frame and best reinforce cast frame
3.economic price and high precision
This is one small cnc milling and drilling machine,but as one machine tool,it is better than other same machine.
As it has reinforced column,stable slide ram and entire rigidity of all guideway,worktable.Its precision can achieve 0.01-.0.2mm,it has best quality and best function.
Item |
Unit |
Model:XK7124 |
Worktable size |
mm |
1000 x 240 |
Travel of table X,Y,Z |
mm |
450 x 280 x 400 |
Size of T-Slots |
|
5/14/44 |
Range of spindle speed |
r.p.m |
3000 |
Spindle taper |
|
BT 40 |
Distance from spindle center to column surface |
mm |
300 |
Distance from spindle nose to surface of worktable |
mm |
450 |
Main motor power |
kw |
2.2 |
X,Y axis motor power |
Nm |
4 |
Z axis motor power |
Nm |
15 |
Locating precision |
mm |
0.02 |
Machine weight |
kg |
900 |
Overall dimension |
mm |
1300 x 1400 x 2000 |
