Specifications
Flexographic printing machine for printing adhesive labelsZBS-320G
55(m/min)
320(mm)
3350(kg)
UV flexo adhesive sticker label printing machine
(with computer,with sheet conveyor)
Description of uv flexo adhesive sticker label printing machine
1,Adopt the ceramic anilox cylinder to transfer the ink,
2,Each printing unit adots 360 ° plate-adjustment.
3,Three die-cutting stations, the first and second die-cutting station can do double sides,working, the third die-cutting station can be used as sheeter.
4,computerized web-guiding system is installed in the front of printing unit,it ensures the material always in the right position.(standard configuration).
5,After sheeting in the third die-cutting station, conveyor belt can output the products orderly.
6,unwinding and rewinding tension are auto-controlled by magnetic powder.two rewinders is possible in this machine.
7,video inspecting system is an option ,it can watch the printing quality when in high speed.
8,The ik rollers will be separated from the printing roller, and keep running when the macine stops.
9,Main machine inverter is imported.
10,The machine can finish material-feeding,printing, varmshing, drying, laminating, die-cutting,rewinding and sheeter in a lump. it is an ideal machine for printing note and top-grade adhesive label.
2.Opitioanl parts:
1) UV dryer for each printing station or only one on last station
2) Video Camera for printng inspection
3)cold foil stamping funcation on last station
3. Main technical specification:
Model | ZBS320B | ZBS450B |
Printing speed | 50m/minute | 50m/min |
Printing color number | 4 color or 5 color | 4 color or 5 color |
Max width of paper | 320mm | 460mm |
Max printing wide | 310mm | 450mm |
Max unwinding diameter | 600mm | 600mm |
Max rewinding diameter | 600mm | 600mm |
Printing length | 175-320mm | 175-320mm |
Thickness of flexo plate | 1.7mm | 1.7mm |
Precision of chromatography | ±0.1mm | ±0.15mm |
Overall dimension | 2(L)×1.1(W)×2.1(H)m | 2(L)×1.25(W)×2.1(H)m |
Weight | about 2000kg | about 2200kg |
