Home > Instruments & Meters > Optical Lens & Instrument > Spectrometer > MAYA2000A-HAMAMATSU S9840

MAYA2000A-HAMAMATSU S9840

Name: MAYA2000A-HAMAMATSU S9840
Brand: ToupTek
SKU: 100661297

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

ToupTek

Model Number:

TS309840

Contact Supplier Request Quote Chat Now

Hangzhou ToupTek Photonics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name ToupTek

Model Number TS309840

Wavelength Range 200nm~1100nm

Specifications

1.MAYA2000A(P/N: TS309840)
2.Micro-spectrometer with 200-1100 wavelength range
3.HAMAMATSU S9840 sensor

MAYA2000A-HAMAMATSU S9840 (P/N: TS309840)

Mechanical Parameters
Dimensions (mm)		160×110×60
Weight (g)		900
Detector Specfiation
Detector		HAMAMATSU S9840
Wavelength Response Range (nm)		200-1000
Active Pixels		2048x14
Pixel Size (um)		14×14
Pixel Well Capacity(ke-)		130
Read Out Noise(e- rms)		25
A/D Resolution		16 bit
Dark Current (pA/cm2)		40 (MAX 120)
Photo Response Non-uniformity		±3%
Sensitivity (uV/e-)		4.0
Optical Bench
Optical System		f/4, symmetrical crossed Czerny-Turner
Focal length (mm)		98.5 (Input); 98.5 (Output)
Entrance Aperture (um)		5, 10, 15, 20, 50 etc. width slits or fiber (customizable)
Grating		Various kinds of scoring grating or holographic grating with different grating constants and flare wavelengths (customizable)
Cylindrical Lens		optional
Optical Filter		Band pass or long pass filters to eliminate secondary spectrum
Fiber and Fiber Connection		NA 0.22, SMA905 (customizable)
Spectroscopic
Wavelength Range		Depends on optical grating
Optical Resolution (nm)		0.14-10 FWHM (Depends on grating constant, width of slit and detector model)
SNR		4500:1 (Full signal)
Wavelength Tolerance (nm)		About ±0.2
Dark noise (RMS counts)		50
Integration Time		10um~7.8s
Dynamic Range		2.0×108(system); 5200:1 (single acquisition)
Stray Light		<0.05% at 550nm
Electronics
Power Consumption		400 mA×5 V DC
Data Transfer Speed		Full spectrum into memory every 5 ms at USB 2.0
Computer
Operating System		Windows /XP/Vista/7 /8(32 and 64)
Interface		USB 2.0 (480Mbps), compatible with USB 1.1
Pre-defined System Components
Name	Customizable Parts	Remark
Slit	Width (µm)	10, 20, 50, 100 .etc
Grating	Lines Per Unit (L/mm)	300, 600, 1200, 1800
	Wavelength Range(nm)	200-1100 (User defined, about 650 range with 600 lines/mm grating)
Fiber	Core Diameter (µm)	9, 50, 200, 400, 600 .etc
	Wavelength Range(nm)	200-1100
	Outer Protection Layer	Normal or enhanced jacketing
	Interface Type	SMA 905 (standard) or FC, ST .etc
Detector	Model	HAMAMATSU S9840
Cylindrical Lens	Optional	Enhance system’s light gathering ability
Optional Components
Name		Remark
Light Source		Used for wide range spectral measurements or wavelength calibration: for example halogen tungsten, xenon or argon light sources
Integration Sphere		Used to acquire uniform light
Reflection Measurement Accessory		Components used for reflection spectrum measurements: for example standard reflection board or specialized clamp
Transmission Measurement Accessory		Components used for transmission spectrum measurement: for example sample holder and various kinds of cuvettes
Packing List
Name		Amount
ToupTek Micro-spectrometer		MAYA2000A
Fiber with SMA 905 Interface		1
Mini USB Data Transfer Wire		1
CD of Software and SDK		1

Basic Application for MAYA2000A

ToupTek’s spectrometer is applicable for spectral detection within the wavelength range between 200nm and 1100nm. Due to their high stability and performance, these portable instruments can greatly satisfy the increasing need for their use in scientfic research, industrial manufacture, and online detections and so on. ToupTek Spectrometer is capable of measuring:
