Product Overview
Compact design, ready for the future of clean energy. Drawing on years of experience in billing metering, the FLOWSIC610 is a MID-certified ultrasonic flowmeter designed for hydrogen billing metering: a robust and reliable solution engineered specifically for the demanding operating conditions of hydrogen systems. The FLOWSIC610 is available in all sizes from DN50 to DN400 and meets Class 1 billing accuracy requirements. The optional purity indication feature provides real-time monitoring of hydrogen purity based on the speed of sound.
| Item | Specification |
|---|---|
| Origin | USA |
| Measuring Principle | Ultrasonic transit-time method |
| Measured Parameters | Actual volumetric capacity, actual volume flow, gas velocity, sound velocity |
| Applicable Medium | H2 hydrogen with purity ＞95% |
| Repeatability | ≤ ±0.05% of measured value |
| Accuracy | ≤ ±0.5% (±1.0% for dry calibration) |
| Measurement Uncertainty | ≤ ±0.1% (±0.2%) |
| Minimum Straight Pipe Requirement | DN100: Inlet straight pipe ≥10DN or ≥2DN+FC+3DN, outlet ≥3DNDN50/DN80: Inlet ≥5DN/FC/10DN, outlet ≥3DN |
| Medium Temperature Range | -40 ~ 60 ℃ (-40 ~ 140 ℉) |
| Working Pressure Range | 15 ~ 102.1 bar(g) (217 ~ 1480 psi(g)) |
| Nominal Diameter | DN 400 (16 inch) |
| Metrological Certification | MID 2014/32/EU Class 1 |
| Explosion-proof Standard | IECEx / ATEX IEC 60079, EN 61326-1:2013 |
| Flange Pressure Standard | ASME B16.5/B16.47, B36.19/B36.10 |
| Hazardous Area Certificate | IECEx, ATEX II 2(1) G Ex db ia [ia Ga] IIC T4 Gb |
| Digital Output | 4 channels digital output |
| Frequency Output | 2 channels, max 10 kHz |
| Digital Communication | Dual Modbus RS-485 (Modbus RTU/ASCII), Bluetooth, USB |
Performance Features
Class 1 accuracy
Field-proven flow performance up to 60 m/s (200 ft/s)
Full-bore design with no pressure drop
Wide turndown ratio, up to 1:160
Hydrogen purity indication option
Intrinsically safe and reliable ultrasonic transducers
Sizes from DN50 to DN400
A reliable and trusted provider of metering solutions
Supports energy-equivalent flow measurement
Hydrogen purity indication—provides real-time values for process control
Quick and easy commissioning via FLOWgate
Product Applications
Hydrogen transfer metering, hydrogen transportation and storage, electrolyzer outlet pipelines, and metering at hydrogen compression stations
