Product Overview
The FLOWSIC100-Flare-XT gas flowmeter has a wide range of applications and can measure parameters such as gas velocity, gas volume, mass flow, molecular weight, volumetric flow, and the speed of sound. In addition, the device features intelligent monitoring capabilities and supports predictive maintenance—designed to address both current and future challenges.
| Item | Specification |
|---|---|
| Origin | USA |
| Measuring Principle | Ultrasonic transit-time method |
| Measured Parameters | Mass flow, standard volume flow, actual volume flow, molecular weight, gas volume & mass, gas velocity, sound velocity |
| Measuring Range | 0.03 ~ 120 m/s (0.1 ~ 394 ft/s) |
| Max Measuring Error | Actual volumetric flow: 1 ~ 5% |
| Medium Temperature Range | -196 ~ +280 ℃ (-320 ~ +536 ℉) |
| Working Pressure | 20 bar(g) |
| Nominal Pipe Size | 4 inch |
| Switch Output | Up to 6 channels with optional I/O module |
| Max Current | 70 mA |
| Max Switching Frequency | 50 Hz |
| Max Input Voltage | 30 V DC |
| Max Saturated Output Voltage | 0.5 V DC |
Performance Features
Reliable measurement even under high gas flow velocities and varying gas compositions
Direct calculation of mass flow without the need for an additional gas analyzer
Intuitive FLOWgate software for commissioning, operation, and diagnostics
Self-monitoring, self-testing, and predictive maintenance
Compliance with multiple standards and guidelines for flare gas measurement
Compatibility with current and future communication architectures
Independent maintenance through on-demand validation and technical support when needed
Easily replaces existing measurement systems and provides suitable retrofit or upgrade solutions
Optional Features and Accessories
Other nominal pipe diameters available upon request
Transmitter/Receiver Unit Accessories
2105581 Weatherproof/UV-resistant cover for active ultrasonic sensor electronics
2108210 Ventilation/drain valve for ultrasonic sensors
2109763 Installation Kit, 2-inch Pipe Assembly, for Interface Unit (Zone 2 and Class 2 only), includes 90° upgrade kit adapter plate
2121461 Installation Kit, 2-inch Pipe Assembly, for Interface Unit (Zone 1 and Class 1 only)
2108970 Weatherproof and UV-resistant cover for interface unit, for wall-mounted installation
2109217 Interface Unit Weather and Sun Shield (Zone 2), includes 2-inch piping installation kit
2121694 Interface Unit Weather and Sun Shield (Zone 1), includes 2-inch piping installation kit
6050602 Infrared/USB Adapter HIE-04
Product Applications
Flare gas measurement in natural gas and associated petroleum gas (APG) production and processing; flare gas measurement in chemical and petrochemical plants; liquefied natural gas (LNG) vapor measurement
