Product Overview
Dosimass is specifically designed for filling and bottling applications in the food, beverage, and life sciences industries. Dosimass directly measures volumetric and mass flow rates and features temperature and density compensation to ensure higher repeatability, unaffected by fluid properties such as viscosity or density. This enables the device to measure liquids with a wide range of properties.
| Item | Specification |
|---|---|
| Origin | USA |
| Measuring Principle | Coriolis force |
| Nominal Diameter | DN 8 (3/8") |
| Measured Variables | Mass flow, density, temperature, volumetric flow |
| Maximum Measuring Accuracy | Liquid mass flow: ±0.15%Liquid density: ±0.0005 g/cm³ |
| Measuring Range | 0 ~ 45000 kg/h (0 ~ 1654 lb/min) |
| Max Medium Pressure | 40 bar (580 psi) |
| Max Process Pressure Rating | PN 40 |
| Display & Operation | No local operation; configuration via operation tool |
| Output | Passive pulse/frequency/switch output |
| Input | None |
| Digital Communication | Modbus RS485, IO-Link |
| Power Supply | DC 20 ~ 30 V |
| Medium Temperature Range | -40 ~ +130 ℃ (-40 ~ +266 ℉)Short-time operation: 1 hour at 150 ℃ |
| Ambient Temperature Range | -20 ~ +60 ℃ (-4 ~ +140 ℉) |
| Sensor Housing Material | Stainless steel 1.4301 (304) |
| Transmitter Housing Material | Stainless steel 1.4409 (CF3M) |
| Wetted Parts Material | Measuring tube: 1.4539 (904L)Process connection: 1.4539 (904L) |
| Protection Class | IP67, Type 4X enclosure |
| Pollution Degree | 4 |
| Relative Humidity | 95% for indoor and outdoor damp & wet areas |
| Operating Altitude | ≤ 2000 m (6562 ft) above sea level |
| Compliance Standard | EN 61010-1 |
Performance Features
High process protection
High Measurement Accuracy Across Different Media
Multivariable Measurement (Flow Rate, Density, Temperature)
No Inlet or Outlet Piping Required
Flexible, Time-Saving Wiring
Quick Commissioning with Preconfigured Equipment
Automatic Data Recovery for Maintenance Purposes
Selection Guide
This lightweight sensor is available in three electronic versions:
Pulse/Frequency/Status version, suitable for filling applications—easy to operate and cost-effective
Smart pulse version with IO-Link, providing continuous digital communication for easy commissioning and documentation, enabling real-time access to process data to optimize filling conditions and enable predictive maintenance
Integrated dosing version, providing dynamic drip correction via Modbus RTU for filling control
Optional Features and Accessories
Set of 10 cover gaskets, Dosimass 71635598
Commubox FXA291 (hardware) 51516983
Adapter FXA291 Dosimag/Dosimass Kit 71035809
Connection Cable RKWTN8-56/5 P92, 5 m 50107895
M12x1 Adapter Set, 8-pin to 4-pin, 4-conductor, 0.2 m 71703755
Sensor Mounting Kit 71392563
Dosimass, D8AB
Product Applications
Food and Beverage, Water Treatment, Wastewater and Waste Management, Oil and Gas/Marine, Life Sciences, Chemical, Power and Energy, Mining, Minerals and Metals, Utilities—Steam
