Product Description
The Flowfit CPA25 flow assembly is specifically designed for establishing measurement points in water treatment, wastewater treatment, and industrial auxiliary processes. The assembly accommodates three sensors and keeps them submerged in the liquid even during flow interruptions, thereby extending their service life. The assembly itself is made of corrosion-resistant polypropylene, ensuring durability. The Flowfit series provides solutions that meet standard application requirements. The Flowfit CPA25 is widely applicable in industrial auxiliary processes as well as in water and wastewater treatment.
| Item | Specification |
|---|---|
| Origin | USA |
| Measuring Principle | Potentiometric method |
| Mounting Type | Flow assembly |
| Design Structure | 3 × PG13.5 sensor ports |
| Process Temperature | 0 to 80 ℃ (32 to 176 ℉) |
| Max Process Pressure | 6 bar (87 psi) |
| Flow Velocity | 4.5 to 5.5 m/s |
| Ambient Temperature Range | -15 to +60 ℃ (5 to +140 ℉) |
| Storage Temperature | -15 to +60 ℃ (5 to +140 ℉) |
| Shaft Length | 120 mm (4.72 in) |
| Bracket Material | Polypropylene (PP) |
| Sealing Material | Optional EPDM or FKM |
| Approx. Weight | 0.8 kg (1.8 lbs) |
Features
Suitable for pressure environments up to 6 bar
Compact design with three Pg 13.5 sensor slots
Special flow channel geometry ensures that installed sensors provide reliable and stable measurements
Siphon-type flow channel design prevents sensors from drying out during equipment downtime
Access cover facilitates sensor cleaning and assembly
Sensors can be calibrated while installed
Optional Features and Accessories
CPA25 Seal Kit (EPDM) 71572882
CPA25 Seal Kit (FKM) 71572884
CPA25 Protective Cover Kit 71572887
CPA25 Maintenance Cover Kit 71573088
CPA25 Cover Plate Kit 71573103
CPA25 PML 316L/EPDM Kit 71573106
CPA25 PML Titanium/EPDM Kit 71573116
CPA25 PML 316L/FKM Kit 71573119
CPA25 PML Titanium/FKM Kit 71573121
CPA25 PG13.5 Screw Plug Kit 71573122
Silicone Sealant Kit 71573128
CPA25 Cleaning Brush Kit 71573123
CPA25 Mounting Bracket (Rail/Pipe) Kit 71573126
CPA25 Kit with 2 G1“–G1/2” Adapters 71604521
CPA25 Kit with 2 G1“–G3/4” Adapters 71604519
Product Applications
Drinking water, water and wastewater treatment, water-cooled circulation systems, reverse osmosis systems
