Short Description
SNR-K750S is an industrial barcode reader card issuer module designed for self-service kiosks requiring controlled card issuing, barcode verification and card recycling. Integrating card dispensing, 1D/2D barcode scanning and card recycling functions in one module, K750S supports QR Code, Data Matrix, PDF417 and other common barcode formats. With optional 50/100/150/200 card capacity, RS232 communication and reliable motor-driven card transport, it is ideal for ticketing kiosks, parking systems, access control terminals and visitor management applications.
Product Overview
SNR-K750S is an advanced barcode reader card issuer module designed for industrial self-service terminals.
Unlike standard card dispensers, K750S integrates:
Card issuing
Barcode scanning
Card recycling
into one compact module.
During the card issuing process, the built-in barcode reader can identify barcode information on cards, enabling terminals to verify card data before output.
It is designed for unattended kiosk applications requiring controlled card distribution and card management.
Key Features
3-in-1 Card Issuing Solution
SNR-K750S combines:
Automatic card dispensing
1D/2D barcode reading
Card recycling
Benefits:
Simplifies kiosk hardware design
Reduces integration complexity
Enables closed-loop card management
Integrated 1D / 2D Barcode Reader
K750S supports configurable barcode reading for different applications.
Supported 2D codes:
QR Code
Micro QR
Data Matrix
PDF417
Micro PDF417
Aztec
Maxicode
Hanxin Code
Dotcode
Supported 1D codes:
Code128
EAN13
EAN8
UPC-A
UPC-E
Code39
Code93
Code32
Card Recycling Function
K750S supports automatic card recycling.
Applications:
Used ticket collection
Returned access cards
Visitor card recycling
Recycle box capacity:
28-30 cards based on 0.76mm thickness
Flexible Card Capacity Options
Optional card box capacities:
50 cards
100 cards
150 cards
200 cards
(Based on 0.76mm card thickness)
Advantages:
Suitable for different project requirements
Supports both small and high-volume deployments
Reliable Motorized Card Transport
The card transport system uses:
Motor-driven card movement
Rubber roller mechanism
Hook-style dispensing structure
Benefits:
Stable card feeding
Reliable card output
Long service life
Intelligent Warning Functions
Built-in monitoring functions include:
Low card warning
Empty card warning
Card box misalignment warning
Full recycle box warning
Automatic Safety Gate Design
The mechanical safety gate helps prevent:
Incorrect card insertion
Incomplete card entry
Card handling errors
Improves terminal reliability in unattended environments.
Applications
Self-Service Ticket Issuing Kiosk
Applications:
Ticket card issuing
Barcode ticket verification
Transportation terminals
Benefits:
Automated card distribution
Barcode validation
Card recycling
Parking Card Issuing System
Applications:
Parking access terminal
Parking payment kiosk
Parking card recycling
Access Control System
Applications:
Visitor access cards
Security card issuing
Temporary access management
Membership & Loyalty Card Kiosk
Applications:
Membership card issuing
Voucher card systems
Loyalty card terminals
Event Ticket Card System
Applications:
Event admission terminals
Smart ticket kiosks
Self-service ticket machines
Technical Specifications
| Item | Specification |
|---|---|
| Model | SNR-K750S |
| Product Type | Barcode Reader Card Issuer |
| Functions | Card Issuing + Barcode Scanning + Recycling |
| Barcode Support | 1D / 2D Barcode |
| Interface | RS232 |
| Power Supply | 24VDC ±10% |
| Card Size | 85.47-85.9 × 53.92-54.18mm |
| Card Thickness | 0.7-1.2mm |
| Card Material | Paper Cards / Polyester Cards |
| Card Box Capacity | 50 cards standard / 100-200 optional |
| Recycle Box Capacity | 28-30 cards |
| Transport Speed | 210mm/s ±10% |
| Issuing Speed | 130mm/s ±10% |
| Card Reading Time | Approx. 1.5s |
| Card Exit Length | 35mm ±2mm |
| Weight | Approx. 1.6kg |
Integration Advantages
Designed for Kiosk System Integrators
K750S is optimized for embedded kiosk projects where issued cards require barcode identification.
RS232 Host Communication
Supports:
Host command control
Embedded system integration
Industrial terminal communication
Self-Test Capability
Supports:
Power-on self-test
Operation self-test
Command self-test
Improves maintenance efficiency.
Why Choose SNR-K750S?
More Than a Card Dispenser
Compared with traditional card dispensers, K750S adds:
Barcode verification
Card recycling
Warning monitoring
Optional high-capacity card box
Designed for Controlled Card Issuing Workflow
Ideal for projects requiring:
Card identification before output
Automatic card distribution
Used card collection
Customization Options
Available:
Card box capacity customization
Barcode module configuration
Mechanical mounting customization
Communication protocol customization
OEM branding
FAQ
Q1: What is SNR-K750S?
SNR-K750S is a barcode reader card issuer module combining card dispensing, barcode scanning and recycling functions.
Q2: What barcode types does K750S support?
It supports common 1D and 2D barcodes including QR Code, Data Matrix, PDF417, Code128 and EAN.
Q3: Does K750S support card recycling?
Yes. It includes a recycle box for collecting returned cards.
Q4: How many cards can it store?
Standard capacity is 50 cards, with optional 100/150/200 card boxes.
Q5: What communication interface does it use?
SNR-K750S uses RS232 half-duplex communication.
