The camera is an industrial-grade USB camera module purpose-built for vehicle and outdoor monitoring scenarios. Powered by a high-sensitivity 1/2.7" CMOS sensor and HDR wide dynamic technology, it delivers sharp, well-balanced imaging even under backlight and high-contrast lighting conditions.
With automatic infrared night vision, IP66-rated sealed housing and 120° wide-angle lens, this camera supports 24/7 uninterrupted monitoring. Its rugged design and plug-and-play USB interface make it ideal for outdoor security, fleet management and in-vehicle surveillance integration.
Core Features
1080P Full HD with HDR TechnologyAdopts a 1/2.7" CMOS image sensor, supporting 1920×1080 resolution at 30fps. HDR wide dynamic technology effectively suppresses overexposure and compensates for dark areas, ensuring clear image output in complex lighting environments such as strong sunlight and night backlight.
Automatic IR Night Vision for 24/7 MonitoringEquipped with 6 high-performance infrared LEDs with a maximum night vision distance of 5 meters. The camera automatically switches between day color mode and night infrared mode according to ambient brightness. Minimum illumination reaches 0.01 Lux (color mode) and 0 Lux (IR activated), realizing all-day continuous surveillance.
IP66 Industrial Protection GradeMade of high-strength aluminum alloy with a fully sealed structure, achieving IP66 dustproof and waterproof performance. It operates stably in rain, dust, high temperature and cold environments, with an operating temperature range of -20°C to +60°C, fully adapting to various outdoor harsh working conditions.
Driver-free USB 2.0 Plug & PlayStandard USB 2.0 interface compliant with UVC protocol, no additional driver installation required. Compatible with Windows, Linux, Android and other mainstream operating systems, powered by 5V USB-A port, easy for rapid integration and on-site deployment.
Wide Angle Lens & Adjustable Mounting Bracket120° wide-angle lens provides a larger field of view and effectively reduces monitoring blind spots. The mounting bracket supports 0-180° tilt adjustment, allowing flexible angle setting according to installation requirements. The 3-5 meter long cable meets the wiring needs of vehicle and outdoor installation scenarios.
Detailed Specifications
| Parameter | Specification |
|---|---|
| Image Sensor | 1/2.7" CMOS |
| Max. Resolution & Frame Rate | 1920 × 1080 @ 30fps |
| Interface | USB 2.0, UVC compliant |
| Power Supply | USB-A 5V DC |
| Lens | Fixed focus, 120° wide angle |
| Night Vision | 6 × IR LEDs, max. 5m effective distance |
| Minimum Illumination | 0.01 Lux (Color mode); 0 Lux (IR mode on) |
| HDR Function | Supported |
| Housing Material | Aluminum alloy |
| Protection Rating | IP66 dustproof & waterproof |
| Bracket Adjustment | 0° - 180° tilt |
| Cable Length | 3 - 5 meters |
| Working Temperature | -20°C ~ +60°C |
| Product Dimension | Approx. 75 × 78 × 55 mm |
| Color | Black |
| Condition | 100% Brand new |
| Customization | OEM/ODM supported, logo printing available |
Application Scenarios
Outdoor Security: Residential courtyards, private garages, retail store entrances, logistics warehouses, construction sites
In-vehicle Monitoring: Truck rear view, bus interior surveillance, taxi/ride-hailing safety recording, engineering vehicle monitoring
Fleet Management: Corporate vehicle fleets, public transit systems, logistics & delivery vehicle tracking
Company Profile
Shenzhen Ruishi Technology Co., Ltd. is a national high-tech enterprise and Shenzhen "Specialized, Refined, Differential and Innovative" SME, focusing on R&D, production and sales of visual imaging camera modules.
Founded in 2017, with 6.1 million RMB registered capital
R&D center with nearly 30 professional engineers, 80% holding bachelor's degree or above
2000㎡ standard production workshop, including 200㎡ Class 100 clean room and 1000㎡ Class 1000 clean room
Certified with ISO quality management system and ISO14001 environmental management system
Full product portfolio: USB camera modules, MIPI camera modules, AI camera modules, edge computing camera modules
Strong customization capability: support custom lens, sensor, interface, firmware, housing and packaging design
Trade & Service Terms
MOQ: 500 units. Sample orders are available for quality evaluation.
Lead Time: 21 - 28 days after payment and order confirmation
Supply Capacity: 10,000 units per month
Payment Terms: T/T, Trade Assurance and other mainstream methods
After-sales: Three-guarantee service (replacement, repair and refund within warranty period)
Packaging: Standard export carton; customized packaging available upon request
Shipping: Support sea freight, air freight and international express delivery
