CIPP Inversion Liner Machine With Stainless Steel Nozzle, 304 Material, Max Working Pressure 10Bar
Product Spotlights
304 stainless steel nozzle for corrosion resistance; max working pressure 10 bar; supports air or water inversion; compact mobile design; ISO9001 certified; customizable for DN100–DN800 liners; reduces excavation costs; backed by 10+ years of manufacturer experience and global exports.
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
material:
304 stainless steel nozzle
maximum_working_pressure:
10 bar
application:
CIPP pipe rehabilitation
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
60 days
Related Products
-
Energy Saving Compact CIPP Inversion Liner Machine for Residential and Commercial Underground Lateral Pipe RepairNegotiableMOQ: 1 Piece -
CIPP Inversion Liner Machine With 1-Year Warranty, Free Technical Training and On-Site Installation SupportNegotiableMOQ: 1 Piece
-
CIPP Inversion Liner Machine Used for Non-Digging Pipeline Restoration in Underground Utility ConstructionNegotiableMOQ: 1 Piece
-
Industrial CIPP Inversion Liner Machine, PLC Touch Screen, Servo Motor Drive, Inversion Speed 5m/minNegotiableMOQ: 1 Piece
-
Heavy Duty Long Service CIPP Inversion Liner Machine for Long‑distance Storm‑drain Pipeline Renovation WorksNegotiableMOQ: 1 Piece
material
304 stainless steel nozzle
maximum_working_pressure
10 bar
application
CIPP pipe rehabilitation
inversion_method
air or water inversion
compatible_liner_types
fabric liners, felt liners
control_system
manual / semi-automatic (optional)
dimensions
customizable per order
weight
varies by configuration
port_of_shipment
Qingdao, China
certifications
ISO9001, ISO14000, OHSAS18001
Qingdao Yongke Machinery Co., Ltd., a reputable manufacturer since 2010 with ISO9001, ISO14000, and OHSAS18001 certifications, proudly presents the CIPP Inversion Liner Machine with Stainless Steel Nozzle, 304 Material, Max Working Pressure 10Bar. Designed for efficient and reliable trenchless pipe rehabilitation, this machine ensures precise inversion of CIPP liners into damaged pipelines. The high-grade 304 stainless steel nozzle guarantees corrosion resistance and durability, even under continuous 10 bar operating pressure. With over a decade of industry experience and annual exports exceeding US$1 million, our equipment is trusted by clients across North America, South America, Europe, Asia, and Africa.
Key Product Features
- Durable 304 Stainless Steel Nozzle – Resists rust and chemical degradation, ensuring long service life in wet and harsh environments.
- Max Working Pressure: 10 Bar (145 PSI) – Provides sufficient force for inverting liners of various thicknesses and lengths.
- Efficient Inversion Process – Compatible with both air and water inversion methods, allowing flexibility based on job site conditions.
- User-Friendly Operation – Simple control panel with pressure gauge and quick-release couplings for hose attachment.
- Compact and Mobile Design – Mounted on a sturdy frame with wheels or skids for easy transportation and positioning.
- Customizable Options – Available with different nozzle sizes, hose lengths, and trolley configurations to match specific project requirements.
Technical Specifications
| Parameter | Value |
|---|---|
| Nozzle Material | 304 Stainless Steel |
| Maximum Working Pressure | 10 Bar (145 PSI) |
| Applicable Liner Diameter Range | DN100 – DN800 (customizable) |
| Inversion Medium | Compressed Air or Water |
| Hose Connection Size | 2 inch / 50 mm (standard) |
| Overall Dimensions (L×W×H) | 1200×600×800 mm (approximately) |
| Weight | About 85 kg |
| Product Certifications | ISO9001, ISO14000, OHSAS18001 |
Advantages & Benefits for Customers
- Reduced Downtime – Rapid inversion speeds up the rehabilitation process, minimizing disruption to traffic or business operations.
- Superior Sealing Performance – Consistent pressure ensures intimate contact between liner and host pipe, forming a seamless corrosion-proof lining.
- Low Maintenance – The 304 stainless steel nozzle resists scaling and wear, requiring minimal cleaning and part replacement.
- Versatility – Works with standard CIPP resin-impregnated felt liners as well as fabric liners, suitable for gravity sewers, storm drains, and industrial pipes.
- Cost-Effective – Eliminates the need for excavation, reducing overall project costs by up to 40% compared to traditional pipe replacement.
- Safety First – Equipped with overpressure relief valve and pressure gauge for safe operation, meeting OHSAS18001 standards.
At Qingdao Yongke Machinery Co., Ltd., we combine cutting-edge manufacturing with strict quality control. Our factory spans 10,000–30,000 square meters and employs 51–100 skilled professionals. With an annual export value of US$1 million to US$1.5 million, we have shipped thousands of CIPP machines to over 20 countries and regions worldwide. Our ISO9001 quality management system ensures every unit is tested for pressure integrity and material compliance before delivery. Backed by a dedicated after-sales team, we offer free technical support, spare parts availability, and on-site training for first-time users. Choose Yongke for reliable, high-performance CIPP inversion equipment that delivers consistent results.
Frequently Asked Questions
-
Q: What is the maximum pipe diameter this machine can handle?
A: The standard model supports liners from DN100 to DN800. For larger diameters, please contact us for a customized solution. -
Q: Can this inversion liner machine be used with water inversion instead of air?
A: Yes, the machine is designed for dual-medium operation. You can choose compressed air or water depending on the liner type and site conditions. -
Q: Does the nozzle come with different size options?
A: The standard nozzle is sized for 2-inch hose connection. We can provide adapters or alternative nozzle diameters upon request. -
Q: What maintenance is required for the stainless steel nozzle?
A: 304 stainless steel is highly resistant to corrosion. Regular cleaning with water and a soft brush is sufficient. Inspect O-rings and seals periodically. -
Q: Is training provided for first-time users?
A: Yes, we offer free online or on-site training (travel expenses may apply). Our technical team will guide you through setup, operation, and troubleshooting. -
Q: What is the warranty period?
A: We provide a standard 12-month warranty on the entire machine, excluding wear parts. Extended warranty is available as an option. -
Q: Can I integrate this machine with my existing CIPP equipment?
A: Absolutely. The inversion machine features universal hose couplings and a simple control interface, making it compatible with most resin mixing units and liner systems. -
Q: What safety features does the machine have?
A: It includes a pressure relief valve, a precision pressure gauge, and a lockable shut-off valve. All components comply with OHSAS18001 safety standards.
Contact us today for a competitive quote and fast delivery from Qingdao port. Let Qingdao Yongke be your trusted partner in pipe rehabilitation!
