Help CenterFood Grade Fiberglass Reinforced Plastic FRP Storage Tank Non-Toxic FRP Vessel for Food Liquid Storage
Product Spotlights
Related Products
-
FRP Ultra Pure Water Tank | GRP Nitrogen Sealed Water Tank - ManufacturerNegotiableMOQ: 1 Cubic Meter -
Custom FRP Storage Tank Fiberglass Reinforced Plastic Vessel for General Chemical Liquid StorageNegotiableMOQ: 1 Piece
-
Vertical Wound Fiberglass FRP Tank for Dilute Sulfuric Acid Storage With Anti-Corrosion LinerNegotiableMOQ: 1 Piece
-
High Strength FRP Tank for Hydrochloric Acid Storage Solutions, Custom SizesNegotiableMOQ: 1 Piece
-
FRP Chemical Storage Tank for Hydrochloric Acid – Corrosion Proof DesignNegotiableMOQ: 1 Piece
Welcome to Hengshui City Yike Composite Materials Co., Ltd. – established in 2009 and proudly serving global markets including North America, South America, Europe, Asia, Africa, and Oceania. Our Food Grade Fiberglass Reinforced Plastic (FRP) Storage Tank is engineered specifically for safe, non-toxic storage of food liquids such as beverages, dairy products, edible oils, and syrups. Combining decades of composite expertise with strict food-grade standards, this tank offers superior corrosion resistance, lightweight construction, and exceptional durability – making it the ideal choice for the food industry.
Key Features & Benefits:
100% Non-Toxic Material: Manufactured with food-grade resin and glass fibers that comply with FDA and EU food contact regulations. No harmful chemicals leach into stored liquids, ensuring product purity.
Excellent Corrosion Resistance: FRP naturally withstands acidic, alkaline, and saline environments, eliminating the need for internal linings or coatings that could contaminate food.
Lightweight Yet Strong: Weight is approximately 1/4 that of steel, reducing transportation and installation costs. High tensile strength (up to 300 MPa) ensures long-term structural integrity.
Smooth Inner Surface: The non-porous gel coat finish prevents bacterial growth and makes cleaning and sterilization easy – perfect for CIP (Clean-in-Place) systems.
Customizable Dimensions & Configurations: Available in vertical, horizontal, or special shapes. Capacity ranges from 500 liters to over 100,000 liters. Custom inlets, outlets, manholes, vents, and level indicators can be added.
Thermal Insulation Option: Optional insulation layers maintain stable temperature for sensitive liquids like milk or juice.
| Parameter | Specification |
|---|---|
| Material Grade | Food-grade isophthalic polyester / vinyl ester resin |
| Working Temperature | -20°C to +80°C (higher available upon request) |
| Maximum Pressure | Atmospheric to 0.5 MPa (customizable) |
| Wall Thickness | 5 mm – 30 mm (designed per tank size and load) |
| Standard Fittings | Flanged inlet/outlet, vent, manhole (sizes customizable) |
| Color | White, blue, green, or custom RAL |
Technical Advantages for Your Business:
Long Service Life: FRP tanks can last 20+ years under normal conditions, reducing total cost of ownership.
Fast Installation: Lightweight structure allows quick on-site assembly; no heavy lifting equipment needed.
Low Maintenance: No rust, no painting required. Simply rinse and sanitize.
Environmentally Friendly: 100% recyclable materials and low energy consumption during manufacturing.
Since 2009, Hengshui Yike has exported over US$1.5–2.5 million worth of composite products annually to more than 15 countries and regions across North America, Europe, Southeast Asia, and Africa. Our tanks are used in well-known beverage factories, dairy plants, and food processing facilities worldwide. Every tank undergoes strict quality control – from raw material inspection to pressure testing and surface finish verification.
Why Choose Hengshui Yike?
10+ years of specialized FRP manufacturing experience
Flexible customization: CAD design, mold making, and full assembly support
Reliable shipping: From Tianjin Port or Shanghai Port with professional export packing
After-sales support: Technical documentation, installation guidance, and spare parts supply
Frequently Asked Questions (FAQ)
Q1: Is this FRP tank safe for drinking water or food contact?
A1: Yes, the inner surface is made from food-grade resin and gel coat that meet international food contact standards. No toxic substances migrate into the stored liquid.Q2: What is the maximum capacity you can produce?
A2: Our standard range covers 500L to 100,000L. Larger capacities (e.g., 200,000L) can be manufactured upon request with reinforced design.Q3: Can the tank be used for hot liquids?
A3: Standard working temperature is up to 80°C. For higher temperatures (e.g., 120°C), we can use special resin formulations – please consult our engineers.Q4: Do you provide installation service overseas?
A4: We offer detailed installation manuals and remote technical support. On-site supervision can be arranged for large projects at an additional cost.Q5: What kind of fittings do you include?
A5: Standard fittings include a manhole, vent, inlet/outlet flanges, and drain. Extra fittings (e.g., level gauges, CIP nozzles, temperature sensors) are optional.Q6: How long does it take to manufacture and deliver?
A6: Typical lead time is 2–4 weeks after order confirmation, depending on size and customization. Urgent orders can be negotiated.Q7: Is the tank resistant to UV and outdoor weather?
A7: Yes, we add UV inhibitors to the outer gel coat. For extreme outdoor exposure, an optional weather-resistant topcoat is available.Q8: What certifications do your tanks hold?
A8: Our products are designed to comply with general food safety requirements. Specific certifications (e.g., NSF, FDA) can be supplied upon request for an additional fee – please contact our sales team to confirm feasibility.
Contact Hengshui City Yike Composite Materials Co., Ltd. today to discuss your food liquid storage needs. Our team will provide a customized solution with competitive pricing, fast delivery, and reliable support. Your success is our priority!
