Hengshui City Yike Composite Materials Co., Ltd. has been a trusted manufacturer of FRP (Fiberglass Reinforced Plastic) tanks since 2009, specializing in custom-sized fiberglass storage solutions for corrosive chemicals. Our Custom Size FRP Fiberglass Tank is expertly engineered for dilute hydrochloric acid liquid storage and treatment, offering exceptional corrosion resistance, structural integrity, and long service life. With years of experience serving global markets, we understand the critical requirements for safe acid containment, and our tanks are designed to meet the most demanding industrial applications. Whether you need a compact 500-liter tank or a large 100 m³ vessel, we provide tailored dimensions, wall thicknesses, and fittings to match your specific process conditions.
Our FRP tanks are manufactured using high-quality vinyl ester or polyester resin combined with E-glass fiber, ensuring excellent chemical resistance against dilute hydrochloric acid (up to 20% concentration at ambient to moderate temperatures). The fabrication process follows strict quality control procedures, including hand lay-up or filament winding techniques, depending on the size and performance requirements. Below, we outline the key features, technical specifications, and benefits that make our tanks the preferred choice for chemical storage.
Key Features & Benefits
- Outstanding Corrosion Resistance: The inert FRP material withstands dilute hydrochloric acid, preventing metal contamination and degradation typical of steel tanks.
- Customizable Dimensions: Diameter, height, wall thickness, and capacity are all tailored to your site constraints and process volumes.
- Lightweight & High Strength: FRP offers a high strength-to-weight ratio, simplifying transportation and installation without compromising durability.
- Long Service Life: Properly designed FRP tanks can last 15-20+ years with minimal maintenance, reducing total cost of ownership.
- Reduced Maintenance: Non-porous surface resists scale buildup and is easy to clean; no need for liners or coatings.
- Versatile Fittings: We can add flanged connections, manholes, vents, drains, level indicators, and other accessories as per your requirements.
- Safe for Dilute Acid Treatment: Special resin grades (e.g., vinyl ester) provide superior acid resistance even at elevated temperatures (up to 90°C, depending on formulation).
- Environmentally Friendly: FRP tanks do not leach contaminants, and the material is recyclable at end of life.
Technical Specifications (Typical Values – Customizable per Project)
| Parameter | Specification / Range |
|---|---|
| Material | FRP (Vinyl Ester / Isophthalic Polyester Resin + E-glass Fiber) |
| Applicable Medium | Dilute hydrochloric acid (up to 20% concentration), other mild acids, alkaline solutions (custom resin required for strong acids) |
| Working Temperature | -20°C to +90°C (depending on resin type, higher upon request) |
| Design Pressure | Atmospheric to 0.5 MPa (higher available with reinforced design) |
| Wall Thickness | 6 mm – 20 mm (designed per diameter, height, and fluid density) |
| Diameter | 500 mm – 4000 mm (custom) |
| Height / Length | 1000 mm – 10000 mm (custom) |
| Capacity | 100 liters – 100 m³ (larger available upon request) |
| Fittings & Accessories | Inlet/outlet flanges (ANSI/DIN), manhole (top/side), vent, drain, level gauge, ladder, platform (all optional) |
| Color | Standard beige / gray; any RAL color available |
| Standards | Designed according to ASME RTP-1 or Chinese GB standards (applicable upon customer request) |
Our engineering team also provides finite element analysis (FEA) for critical applications, ensuring stress distribution meets safety factors. Each tank undergoes hydrostatic pressure testing and spark testing for pinhole detection before shipment.
Why Choose Yike Composite Materials?
- Experience Since 2009: Over 15 years of dedicated FRP manufacturing expertise, exporting to North America, South America, Europe, Africa, Asia, and Oceania.
- Annual Export Value US$1.5M–2.5M: Proven track record delivering high-quality tanks overseas, with reliable logistics from Tianjin and Shanghai ports.
- Flexible Customization: We work with you from concept to installation, offering 3D drawings, material certificates, and on-site technical support if needed.
- Competitive Lead Times: Typical production 15–30 days for standard custom tanks, depending on complexity and order volume.
- Quality Assurance: All raw materials (resin, fiberglass) sourced from reputable suppliers, with incoming inspection and in-process quality checks.
With a strong foothold in the global market, our tanks have been utilized in chemical processing plants, water treatment facilities, electroplating industries, and mining operations. We take pride in offering products that meet the specific needs of each client, whether it’s a high-temperature dilute hydrochloric acid storage or a low-pressure treatment system.
Ready to discuss your project? Contact our sales team today for a free consultation and customized quotation. We will be happy to provide technical datasheets, previous case studies, and a detailed design proposal for your dilute hydrochloric acid storage tank. Trust Yike Composite Materials for durable, reliable, and cost-effective FRP solutions.
Frequently Asked Questions (FAQ)
-
Q1: Can your FRP tank store concentrated hydrochloric acid (above 20%)?
Our standard design using vinyl ester resin is suitable for dilute acid (≤20%). For higher concentrations, we recommend a specialized dual laminate or PTFE-lined FRP tank. Please provide your specific concentration and temperature for a tailored solution. -
Q2: What is the typical lead time for a custom-size tank?
Standard custom tanks (up to 50 m³) can be produced within 15–30 working days after design approval. Larger or more complex orders may require 30–45 days. -
Q3: Do you provide installation guidance or on-site support?
Yes, we offer detailed installation manuals and optional remote guidance. For large projects, our engineers can visit your site (travel costs apply). We also work with local partners in many regions. -
Q4: How do I determine the required wall thickness for my application?
Our engineers calculate wall thickness based on tank diameter, height, fluid density, working temperature, and desired safety factor. We will provide a design calculation sheet for your approval before production. -
Q5: Is the tank UV resistant if installed outdoors?
Yes, we can add a UV-resistant gel coat (e.g., ISO-NPG type) to protect against sunlight degradation. For outdoor installation, we recommend specifying this option. -
Q6: What testing is performed before shipment?
Each tank undergoes a hydrostatic test at 1.5 times the design pressure (or full water fill for atmospheric tanks), plus a spark test for dielectric integrity. Material certificates and test reports are provided upon request. -
Q7: Can you integrate the tank with my existing piping and equipment?
Absolutely. We can customize nozzle locations, orientations, and flange standards (ANSI, DIN, JIS, etc.) to match your system. Please provide your piping diagram or requirements. -
Q8: What warranty do you offer?
We provide a standard 12-month warranty against manufacturing defects from the date of shipment. Extended warranty options are available upon negotiation.
