At Hengshui City Yike Composite Materials Co., Ltd., we specialize in engineering high-performance FRP tanks for corrosive chemical storage. Our 20,000 Liter FRP Sodium Hypochlorite Tank is designed to withstand the aggressive nature of sodium hypochlorite while maintaining 15 PSI rated pressure and a maximum operating temperature of 120°F. With over a decade of manufacturing experience (since 2009) and annual export value between US$1.5–2.5 Million, we deliver reliable storage solutions to markets worldwide including North America, Europe, and Southeast Asia.
This tank integrates advanced composite layup technology and corrosion-resistant resin systems specifically formulated for sodium hypochlorite service. Whether you need a stand-alone storage vessel for water treatment plants or a pressurized dosing tank for industrial bleaching processes, our product offers exceptional durability, low maintenance, and cost-effective performance.
Below we detail the construction, key features, and technical specifications that make this tank a trusted choice for chemical storage professionals.
Key Features & Benefits
Corrosion-Resistant Construction: Made from FRP (Fiberglass Reinforced Plastic) with a specially selected vinyl ester or epoxy resin liner to resist the oxidizing effect of sodium hypochlorite, preventing pitting and degradation over extended service life.
Pressure Rated Design: Rated for 15 PSI (1.03 bar) – suitable for gravity feed, pump discharge, or moderate pressure systems. This allows integration into closed-loop dosing systems without additional pressure vessels.
High Temperature Tolerance: Maximum operating temperature of 120°F (49°C) ensures safe storage even in warm climates or when handling partially heated recirculated bleach solutions.
Large 20,000 Liter Capacity: Equivalent to 5,283 US gallons, ideal for municipal water treatment, pulp & paper mills, textile bleaching, or bulk chemical distribution centers.
Lightweight & Easy Installation: FRP is approximately one-quarter the weight of steel, reducing foundation and handling costs. The tank can be delivered as a single piece (vertical) or in sections for field assembly (horizontal).
UV Protection: Outer gel coat with UV inhibitors prevents sunlight degradation when installed outdoors, maintaining structural integrity and appearance for years.
Customizable Nozzles & Fittings: We offer flexible configuration options including various flange sizes, vent connections, drain ports, and manways – tailored to your piping and instrumentation requirements.
Technical Specifications (Standard Version)
| Total Capacity | 20,000 Liters (5,283 Gallons) |
| Design Pressure | 15 PSI @ 120°F (1.03 bar @ 49°C) |
| Nominal Dimensions | Approx. Diameter: 2.5m; Height: 4.5m (vertical configuration – customizable) |
| Resin System | Vinyl Ester (standard) or Epoxy – choose based on chemical concentration |
| Wall Thickness | Engineered per pressure & load – typically 6–12 mm (custom calculation) |
| Connections | 2" to 4" flanged inlet/outlet (ANSI/DIN); vent; drain; optional 24" manway |
| Finish | Gel coat exterior (UV resistant); smooth interior for easy cleaning |
Why Choose Our FRP Sodium Hypochlorite Tank?
Tailored to Your Chemistry: We can adjust the resin formulation based on your specific sodium hypochlorite concentration (e.g., 12.5% NaOCl) and temperature profile – ensuring maximum chemical resistance.
Rigorous Quality Control: Each tank undergoes hydrostatic pressure testing and vacuum inspection before shipment. Our factory in Hengshui, China, uses computer-controlled filament winding or hand layup, ensuring uniform wall thickness.
Global Shipping Expertise: We ship from Tianjin Port, Shanghai Port, or Tianjin Port (multiple options). Our packaging includes wooden crating, steel skids, and waterproof wrapping to protect the tank during ocean freight.
Fast Lead Time: Standard production takes 4–6 weeks; partial shipments available for bulk orders. We have served clients in North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Middle East, East Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, and domestic China.
Trust & Experience
Hengshui City Yike Composite Materials Co., Ltd. has been manufacturing composite tanks since 2009 – over 15 years of hands-on expertise. Our annual export value of US$1.5–2.5 Million demonstrates the trust customers place in our products. We serve diverse industries including water treatment, chemical processing, and industrial bleaching. Every tank is backed by our commitment to quality and after-sales support. Contact us today to discuss your specific storage requirements or request a customized quotation.
Frequently Asked Questions (FAQ)
Can this tank be used for sodium hypochlorite concentrations higher than 12.5%?
Yes, but the resin selection may need to be upgraded. For concentrations above 15%, we recommend a higher-grade vinyl ester or epoxy liner. Please provide your exact chemical composition and operating temperature for a tailored solution.Is the tank certified to any international standards?
Our tanks are manufactured in accordance with industry guidelines such as ASME RTP-1 and BS 4994 (available upon request). We do not carry third-party certifications unless explicitly ordered and verified.What fittings and accessories can be added?
Options include flanged nozzles, vertical or horizontal orientation, level gauges, pressure relief valves, heating panels (for freeze protection), and manways. All are customizable to your piping system.How do I install the tank and what foundation is required?
The tank should be placed on a level concrete or steel foundation that supports the full weight (approx. 1,500–2,500 kg empty). Anchor bolts and saddles are supplied. A detailed installation manual is provided with every order.What is the typical lifespan of this FRP tank in sodium hypochlorite service?
With proper maintenance (periodic inspection, avoiding thermal shock), the tank can last 15–20+ years. The corrosion-resistant liner is key; regular UV gel coat maintenance extends outdoor life.Can the tank be repaired if damaged?
Yes, FRP tanks are field-repairable using epoxy patching kits. We provide repair guidance and can supply compatible resin if needed.What is the warranty period?
Standard warranty is 12 months from shipment date against manufacturing defects in materials and workmanship. Extended warranty options are available upon request.How long does shipping take to the United States?
Sea freight from Tianjin to US West Coast ports typically takes 18–25 days. Total door-to-door time including customs clearance is usually 30–45 days. We can arrange expedited shipping at additional cost.
For more technical documentation or a customized quote, please contact our sales team at Hengshui City Yike Composite Materials Co., Ltd. We are ready to support your chemical storage needs.
