Help CenterP16 Series 3-Pin Female Socket Non-Sealed P16K2A
Related Products
-
FQ30 Series 14-Pin Square Flange Male Socket FQ30-14ZJNegotiableMOQ: 200 Units -
P16 Series 2-Pin Straight Male Cable Plug With Shielded Tail Attachment P16J1PNegotiableMOQ: 200 Units
-
ZH23 Series Shell Size 22 10 Pin Male Plug With Angled Tail Attachment – СНЦ23-10/22В-8-В ZH23-10/18B-1b-BNegotiableMOQ: 200 Units
-
ZH23 Series Shell Size 22 7 Pin Male Plug With Straight Tail Attachment (Key Position: A) – СНЦ23-7/22В-6А-В ZH23-7/22B-6a-BNegotiableMOQ: 200 Units
-
ZH23 Series Shell Size 18 10 Pin Female Socket With Straight Tail Attachment – СНЦ23-10/18Р-2-ВNegotiableMOQ: 200 Units
Product Details:
The ШР-type circular connector complies with SJ/T10496-94 and includes 8 varieties with P16 and P60 screw thread types. It offers over 1,800 specifications, including straight, angled, shielded, unshielded, sealed, and unsealed versions.
Contact diameters are Φ1.5, Φ2.5, Φ3.5, and Φ5.5 mm, with options for gold or silver plating. It can be matched and interchanged with the original parts of the Russian ШР series.
ATTRIBUTES:
Connector Type: Socket
Shell Size: 16
Contact Size: 3*1.5mm
Connection Method: Thread Connection
Terminal Method: Solder
Plating of Contacts: Silver
Insulator: PBT or Bakelite
Shell: Aluminum Alloy Surface Anodizing Treatment
Relative Humidity: It can reach 95% at 40°C
Ambient Temperature: -55°C~+70°C
Vibration: 10 ˜ 200Hz, 95m/²
Insulated Resistance: Normal Temperature≥ 500mΩ; Wet Heat≥ 2mΩ
Life Duration: 500 Cycles
