1.Features
Usually used with displays, recorders, and computers;
Diverse structures, easy to assemble and replace;
Strong anti-interference, high long-term stability, high mechanical strength;
Good vibration resistance, high measurement accuracy;
Wide measurement range (-200℃ ~ 1800℃);
Fast thermal response, long service life, good pressure resistance;
Small installation space required.
2.Applications
Widely used in industrial automation, food and beverage processing, petrochemicals, water treatment, environmental protection, wastewater and exhaust gas, hydraulics, construction machinery, and other fields for measuring the temperature of liquids, steam, gas, and solid surfaces
3.Technical data
Item |
Specifications |
Range |
-200~1800℃ |
Wetted parts |
316 (Customizable） |
Accuracy |
Class I Class II |
Power supply |
24(18~36)VDC （transmitter),10(6~12)VDC (mV signal) |
Output signal |
4-20mA（wire） |
Thermowell material |
304,316,PTFE |
Process type |
Non-fixed type,Fixed thread type,Loose flange,Fixed flange,Loose flange with angle ,Fixed thread with tapered tube,Straight pipe fitting |
Process connection |
M20*1.5 (Customizable) |
Other |
Explosion-proof version / Integrated design available |
Protection level |
IP65 |
Calibration Type |
E J K N T S R B |
Junction box |
Splash-proof, waterproof, and explosion-proof optional |
Thermowell Diameter |
Φ16mm，Φ25mm |
4.Please provide detailed parameters for selection: Temperature ,measuring media ,process connection ,insertion depth ,material etc.
