Office building entrance and exit gate - Quick access by card swiping or face recognition, anti-pinch and anti-tailing
The entire product outer box is stamped and formed from domestic standard 304 stainless steel plates. The swing gate can provide an orderly and civilized way of passage for people entering and exiting, prevent illegal entry, and the swing arms operate smoothly with low noise. The swing gate can be integrated with various access control devices, such as ID cards, IC cards, barcode cards, mobile phone SIM cards, access control systems, fingerprint machines, palm scanners, face recognition and other identification methods for use.
The swing gate has an elegant appearance, and is rainproof, moisture-proof and rust-proof.
The swing gate comes with a 1-year free warranty for the whole machine and lifetime maintenance.
The swing arms have a synchronization function (double swings open in opposite directions).
The swing gate has a fault self-check and alarm prompt function, which is convenient for users to maintain and use.
When the power is cut off, the swing arms automatically swing open, and when the power is restored, they automatically close, meeting the fire safety requirements.
The swing gate has multiple working modes to choose from, such as two-way card reading, one-way card reading with the other direction prohibited, one-way card reading with the other direction allowing free passage, and the working mode of the gate can be set through the main board menu.
The entire system of the swing gate operates smoothly with low noise.
The swing gate has a function of long-distance control of opening and closing the gate via 485, to meet the special needs and fire safety requirements of users.
The swing gate has an anti-rush function. When no gate opening signal is received, the swing arms automatically lock.
The swing gate has anti-pinch and anti-collision functions. When the swing arms encounter an obstacle during the reset process, the motor automatically stops working within the specified time and restarts after the default delay.
It has a reset function. After the gate is opened, if no one passes through within the specified time, the system will automatically cancel the user's right to pass this time and close the gate automatically.
It can be adjusted to be normally open or normally closed to meet the requirements of different sites.
It can automatically reset by induction or after a delay. The standard is to automatically reset 5 seconds (adjustable) after opening.
It can be externally connected to a switch button or remote control to achieve one-way or two-way controlled passage.
The structure of the swing gate: stainless steel chassis, swing arms, motor, movement and transmission parts, control board, etc.
The manufacturing process of the gate: bending, cutting, welding, polishing, grinding, etc.
The length of the swing arm: 600mm;
The weight: about 80Kg;
The bearing capacity of the swing arm: 60Kg;
The transmission angle of the swing arm: 180 degrees;
The width of the passage: 1200mm;
The swing direction: one-way, two-way;
The working environment: indoor, outdoor (with a rain awning);
The ambient temperature: -30℃～50℃;
The input interface: relay switch signal (COM port is the ground);
The working power supply: power supply voltage: input AC220V±10%, output DC24V, DC12V;
The motor power: DC motor 100W/24V;
The motor speed: 1600 revolutions per minute;
The relative humidity: less than 95% (no condensation);
The communication interface: communication interface: RS485 (distance ≤1200 meters) or TCP/IP;
The passing speed: 40 people per minute (normally open); 25 - 30 people per minute (normally closed);
The opening and closing time of the gate: 1 - 2 seconds;
The time required to enter the passing state after power-on: 3 seconds;
The automatic fault reset time: 10 seconds;
The mechanical service life: more than 3 million times;
Supported card readers: barcodes, ID/IC cards, RFID cards, second-generation ID cards;
Functions and Features:
It has the functions of fault self - inspection and alarm prompt, which is convenient for users to maintain and use.
Through the built - in small keypad on the main control board, the operating status of the device can be programmed.
Anti - pinch and anti - collision functions. When the swing arm encounters an obstacle during the reset process, the motor will automatically stop working within the specified time. After the default delay, it will reset again (until the reset is completed), and the force is very small (≤2Kg).
Anti - rush function. When no gate - opening signal is received, the swing arm will automatically lock.
It has an automatic reset function. After the gate is opened, if the user does not pass within the specified time, the system will automatically cancel the user's right of passage for this time.
It can be freely adjusted to be normally open or normally closed to meet the requirements of different sites.
It can be connected to a variety of card - reading devices and work by receiving relay switch signals.
One - way and two - way swing functions can control the entry and exit of personnel in one - way or two - way mode.
Delayed automatic reset. The system defaults to automatically reset 10 seconds (adjustable) after being opened.
When the power is off, the swing arm will automatically swing open, and when the power is on, it will automatically close, which meets the fire protection requirements.
Application scope of swing gates:
Transportation stations: High - speed railway stations, subway stations, airports, docks, railway stations, bus stations, ferry crossings.
Office places: Government agencies, commercial buildings, detention centers.
Science and education units: Libraries, universities, research institutes, kindergartens.
Commercial places: Banks, hotels, supermarkets, exhibition centers, villas, residential communities.
