Aegir Pedestrian Passage Swing Gate - Dynamic Face Recognition System for Office Building Personnel Access Management
The entire product outer box is stamped and formed with domestic standard 304 stainless steel plates. The swing gate can provide an orderly and civilized passageway for people entering and exiting, prevent illegal entry, and the swing arm runs smoothly with low noise. The swing gate can be integrated with various access control devices, such as ID cards, IC cards, barcode cards, mobile phone SIM cards, access control systems, fingerprint machines, palm scanners, face recognition and other recognition methods.
The swing gate has an aesthetic and generous appearance, and is rainproof, moisture-proof, and rust-proof.
The swing gate comes with a 1-year free warranty for the whole machine and lifetime maintenance.
The swing arm has a synchronization function (double swings open in opposite directions).
The swing gate has a fault self-check and alarm prompt function, which is convenient for users to maintain and use.
The swing arm automatically swings open when the power is off and closes automatically when the power is on, meeting the fire protection requirements.
The swing gate has multiple working modes to choose from. It can read cards in both directions, or read cards on one side and prohibit passage on the other side, or read cards on one side and allow free passage on the other side. The working mode of the gate can be set through the mainboard menu.
The entire system of the swing gate runs smoothly with low noise.
The swing gate has a function of remotely controlling the opening and closing of the gate via 485 to meet the special needs and fire safety requirements of users.
The swing gate has an anti-rush function. When no gate opening signal is received, the swing arm is automatically locked.
The swing gate has an anti-clamping and anti-collision function. When the swing arm encounters an obstacle during the reset process, the motor automatically stops working within the specified time and restarts after the default delay.
It has a reset function. After the gate is opened, if the user does not pass within the specified time, the system will automatically cancel the user's right to pass and close the gate automatically.
It can be adjusted to be normally open or normally closed to meet the requirements of different venues.
It can automatically reset by induction or delay. The standard is to automatically reset 5 seconds (adjustable) after opening.
It can be externally connected to a switch button or a remote control to realize one-way or two-way control of passage.
The structure of the swing gate: stainless steel chassis, swing arm, motor, movement and transmission parts, control board, etc.
The process of the gate: bending, cutting, welding, polishing, grinding, etc.
The length of the swing arm: 600mm;
Weight: about 80Kg;
The bearing capacity of the swing arm: 60Kg;
The transmission angle of the swing arm: 180 degrees;
The width of the passage: 1200mm;
The swinging direction: one-way, two-way;
Working environment: indoor, outdoor (with a rain awning);
Ambient temperature: -30℃～50℃;
Input interface: relay switch signal (COM port is the ground);
Working power supply: power supply voltage: input AC220V±10%, output DC24V, DC12V;
Motor power: DC motor 100W/24V;
Motor speed: 1600 revolutions per minute;
Relative humidity: less than 95% (no condensation);
Communication interface: communication interface: RS485 (distance ≤ 1200 meters) or TCP/IP;
Passage speed: 40 people per minute (normally open); 25 - 30 people per minute (normally closed);
The opening and closing time of the gate: 1 - 2 seconds;
The time required to enter the passage state after power-on: 3 seconds;
The automatic reset time for faults: 10 seconds;
Mechanical life: more than 3 million times;
Supported card readers: barcodes, ID/IC cards, RFID cards, second-generation ID cards;
Functions and Features:
It has the functions of fault self - inspection and alarm prompt, which is convenient for users to maintain and use;
Through the built - in small keypad on the main control board, the operating status of the device can be programmed;
Anti - pinch and anti - collision functions. When the swing arm encounters an obstacle during the reset process, the motor will automatically stop working within the specified time. It will reset again after the default delay (until the reset is completed), and the force is very small (≤2Kg);
Anti - rush function. When the gate - opening signal is not received, the swing arm will be automatically locked;
It has an automatic reset function. After the gate is opened, if the user does not pass through within the specified time, the system will automatically cancel the user's right to pass this time;
It can be freely adjusted to be normally open or normally closed to meet the requirements of different sites;
It can be connected with a variety of card - reading devices and work by receiving relay switch signals;
One - way and two - way swing functions can control the entry and exit of personnel in one - way or two - way mode;
Delayed automatic reset. The system defaults to automatically reset 10 seconds (adjustable) after opening;
The swing arm will automatically swing open when the power is off and automatically close when the power is on, which meets the fire protection requirements.
The visual characteristics of human faces are:
The differences between different individuals are not significant. All human faces have similar structures, and even the structural shapes of facial organs are very similar. Such characteristics are beneficial for face utilization. The access gate system can be developed in this aspect.
The appearance of human faces is very unstable. People can produce many expressions through facial changes, and the visual images of human faces vary greatly from different observation angles. In addition, face recognition is also affected by many factors such as lighting conditions (e.g., day and night, indoor and outdoor) and many coverings on the face (e.g., masks, sunglasses, hair, beards, etc.) and age. The face recognition technology of the access gate can eliminate these difficulties one by one to achieve the ideal application effect.
Access gate
Now, the face recognition technology of access gates is becoming increasingly mature and its development prospect is more and more promising. In China, it is also rapidly popularized in terms of application at present.
The combination of the access gate and the IC card reader constitutes an intelligent access gate integrated management system, which can realize functions such as access control, attendance, and charging. Usually, a set of access gates are set up at the entrances and exits of large - scale conference venues, which facilitates the attendance sign - in of participants and the statistics and query of conference managers.;It provides an easy solution for effectively mastering and managing the entry, exit, and attendance of conference participants. At the same time, it politely refuses the entry of non - participants, ensuring the order of the conference. It greatly reduces the workload of conference service staff and improves the work efficiency of the exhibition.
Application scope of swing gates:
Transportation stations: High - speed railway stations, subway stations, airports, docks, railway stations, bus stations, ferry crossings.
Office places: Government agencies, commercial buildings, detention centers.
Science and education institutions: Libraries, universities, research institutes, kindergartens.
Commercial places: Banks, hotels, supermarkets, exhibition centers, villas, residential communities.
