General Electric IS42yESWAH1A Ethernet switch module
The IS420ESWAH1A (ISx2yESWAH1A, x=4, y=0/1) is a GE Mark VIeS series IONet industrial Ethernet switch module, providing redundant network communication for Mark VIe/VIeS control systems. It is compatible with safety control networks in turbine and process industries, featuring industrial-grade protection, fault tolerance, and hazardous area certification to ensure communication continuity in SIS systems.
Core Performance: Network Interface Capabilities
Copper Ports: Eight 10/100Base-TX (RJ45) ports, supporting HP-MDIX automatic wiring crossover, full/half-duplex auto-negotiation, compatible with field I/O modules and controller connections.
Fiber Optic Port: One 100Base-FX multimode fiber optic port (LC interface) for long-distance/interference-resistant redundant backbone communication, compatible with IONet fiber optic links.
**Cache and Address Table:** 256KB cache, supports 4K MAC addresses, ensuring concurrent communication and flow control for multiple devices and preventing data loss.
**Redundancy and Communication Features:**
**Redundancy:** Power supply redundancy (24-28VDC), supports hot-swapping, compatible with IONet redundant architecture, seamless switching in case of single-link failure, ensuring network continuity for security control.
**Communication:** 10/100M adaptive Ethernet, real-time interaction with Mark VIeS security controllers, supports ControlST remote network diagnostics and configuration.
**Diagnostics:** Port-level LED status indicators (power/link/activity) for quick identification of communication anomalies, supports IEEE 802.3x flow control to prevent network congestion.
**Safety and Environmental Features:**
**Certifications:** Class 1 Div 2/ATEX explosion-proof, suitable for deployment in hazardous areas.
**Environment:** Operating temperature -40℃ to +70℃, DIN rail mounting, natural convection cooling, vibration/shock resistant, adaptable to harsh industrial environments.
Protection: The RJ45 connector supports 200 mating cycles, features a metal housing for protection, and is suitable for frequent maintenance scenarios in industrial settings.
Email: xmxblynn@163.com
Phone: +86 18059884797
Key Technical Parameters
Parameter Value
Model IS420ESWAH1A (Mark VIeS ESWA IONet Ethernet Switch)
Compatible Systems GE Mark VIe/Mark VIeS Control Systems (SIS/Turbine Control)
Port Configuration 8×10/100Base - TX (RJ45) + 1×100Base - FX (LC Multimode Fiber)
Network Features HP-MDIX Auto Wiring, Full/Half-Duplex Auto-Negotiation, IEEE 802.3x Flow Control
Cache/Address 256KB Cache, 4K MAC Address Table
Power Input 24-28VDC Redundant, Phoenix Contact Connector, Hot-Swap
Operating Temperature -40℃ to +70℃
Mounting Method Standard DIN Rail Mount, Supports Vertical/Horizontal Mounting
Compliance Class 1 Div 2, ATEX, CE/UL, Compatible with SIS Systems IEC 61508 SIL 3 Environment
Status: Mark VIeS in-service spare parts for IONet switch replacement and network expansion.
Typical Applications:
Turbine Control Network: The core of the redundant IONet network for Mark VIeS systems in gas/steam turbines, connecting safety I/O modules, controllers, and operator stations to ensure real-time transmission of control signals.
Process Industry SIS Network: The safety communication backbone for petrochemical/chemical SIS systems, adapting to the high-reliability data transmission requirements of emergency shutdowns/safety interlocks.
Redundant Network Deployment: Dual redundancy (power/communication) design, adapting to the high-availability safety network requirements of critical equipment, avoiding system failure due to single points of failure.
Spare Part Replacement and Upgrade: Adapted to existing Mark VIeS systems, used for replacing faulty IONet switches, supporting automatic network configuration recovery to ensure system continuity.
