General Electric IS42yYVIBS1B Vibration input module
The IS420YVIBS1B (ISx2yYVIBS1B, x=4, y=0/1) is a safety-grade vibration input module from the GE Mark VIeS series, meeting IEC 61508 SIL 3 safety requirements. It is used for safety monitoring of shaft vibration, shaft displacement, key phase/speed in turbine machinery, and is compatible with overspeed protection and vibration over-limit interlocking scenarios in SIS systems. It features a TMR redundancy architecture and hazardous area certification.
Core Performance:
Signal Acquisition Capabilities:
Channel Configuration: 13-channel safety vibration input (compatible with eddy current/seismic/dynamic pressure sensors, ±10Vpp), supports key phase/RPM synchronous acquisition, and provides electrical isolation between channels.
Signal Processing:
Sampling frequency 10kHz, input passband 4300Hz, displacement/velocity/pressure measurement accuracy up to ±0.01Vp, suitable for wideband vibration monitoring of turbines.
Diagnostics: Channel-level open/short circuit/drift monitoring; LED indicators for module/channel status; ControlST remote diagnostics for rapid fault location.
Redundancy and Communication Features:
Redundancy: TMR triple architecture, IONet redundant links, seamless switching in case of single module/link failure, ensuring continuous safety monitoring.
Communication: Dual 100M full-duplex Ethernet (IONet redundancy), compatible with Mark VIeS TMR/DCS, supporting real-time vibration data transmission and analysis.
Expansion: Matches IS410TVBAS2B terminal block, suitable for large-scale vibration signal acquisition scenarios.
Safety and Environmental Features:
Certifications: Class 1 Div 2/ATEX explosion-proof, suitable for deployment in hazardous areas.
Environment: Operating temperature -30℃ to 65℃, vibration/shock resistant, adaptable to harsh environments in turbine industries.
Protection: Overvoltage/reverse connection protection, fault isolation, preventing system fault propagation.
Email: xmxblynn@163.com
Phone: +86 18059884797
Key Technical Parameters
Parameter Value
Model IS420YVIBS1B (Mark VIeS YVIB Safety Vibration Input Module)
Compatible System GE Mark VIeS Safety Control System (SIS)
Input Channels 13-channel safety vibration input (±10Vpp, compatible with eddy current/seismic/dynamic pressure sensors)
Sampling Frequency 10kHz, Input Passband 4300Hz
Safety Class IEC 61508 SIL 3, TMR Triple Redundancy
Communication Interface Dual 100M Ethernet (IONet Redundancy)
Power Supply Input 24-28VDC Redundancy, Hot-swappable Design
Operating Temperature -30℃ to 65℃
Installation Method Standard Mark VIeS rack mount, compatible with IS410TVBAS2B terminal block
Compliance Class 1 Div 2, ATEX, CE/UL, IEC 61508 SIL 3
Status Mark VIeS In-service spare parts for replacing safety vibration input modules.
Typical Applications:
Turbine Safety Monitoring: Safe acquisition of parameters such as shaft vibration, shaft displacement, and differential expansion in gas/steam turbines, triggering overspeed protection and emergency shutdown (ESD) for excessive vibration.
Rotating Machinery Safety Interlocks: Vibration monitoring of rotating equipment such as compressors and generators, enabling safe shutdown control.
Redundant Safety Deployment: TMR triple protection ensures continuous safety monitoring, adapting to the high availability and safety requirements of critical equipment.
Spare Parts Replacement and Upgrades: Compatible with existing Mark VIeS systems, used for replacing fail-safe vibration input modules, supporting automatic safety configuration recovery.
Email: xmxblynn@163.com
Phone: +86 18059884797
