General Electric ISx2yYDIAS1B Safe discrete output module
The IS220YDIAS1B/IS420YDIAS1B (ISx2yYDIAS1B, x=2/4, y=0/1) is a safety-grade discrete input I/O module from the GE Mark VIeS series. Meeting IEC 61508 SIL 3 safety requirements, it is used for the safe acquisition of discrete signals in SIS systems. It features a redundant architecture, fail-safe design, and hazardous area certification, making it suitable for emergency shutdown/safety interlock scenarios in turbine and process industries.
Core Performance:
Signal Acquisition Capabilities
Channel Configuration: 16-channel safety discrete input (dry contact/wet contact, 24VDC), electrical isolation between channels, and no single-channel fault propagation.
Signal Processing: Input response time ≤6ms, supports contact jitter filtering, and is suitable for rapid acquisition of safety interlock signals.
Diagnostics: Channel-level open/short circuit monitoring, LED indicators for module/channel status, ControlST remote diagnostics, and rapid fault location.
Power Supply and Communication Characteristics
Power Supply: 24-28VDC redundant input, hot-swappable design, maintenance without interrupting system operation.
Communication: Dual 100M full-duplex Ethernet (IONet redundancy), compatible with Mark VIeS TMR/DCS, seamless switching in case of link failure.
Expansion: Supports terminal block expansion, suitable for large-scale discrete signal acquisition scenarios.
Safety and Environmental Characteristics
Certifications: Class 1 Div 2/ATEX explosion-proof, suitable for deployment in hazardous areas.
Environment: Operating temperature -30℃ to 65℃, vibration/shock resistant, adaptable to harsh industrial environments.
Protection: Overvoltage/reverse connection protection, fault isolation, preventing system fault propagation.
Email: xmxblynn@163.com
Phone: +86 18059884797
Key Technical Parameters
Parameter Value
Model IS220YDIAS1B/IS420YDIAS1B (Mark VIeS YDIA Safety Discrete Input I/O Module)
Compatible System GE Mark VIeS Safety Control System (SIS)
Input Channels 16 safety discrete inputs (24VDC dry/wet contacts)
Response Time ≤6ms, supports contact bounce filtering
Safety Class IEC 61508 SIL 3, fail-safe design
Communication Interface Dual 100M Ethernet (IONet redundancy)
Power Supply Input 24-28VDC redundancy, supports hot-swapping
Operating Temperature -30℃ to 65℃
Installation Method Standard Mark VIeS rack mount
Compliance Class 1 Div 2, ATEX, CE/UL, IEC 61508 SIL 3
Status Mark VIeS in-service spare parts, for replacing safety discrete input modules
Typical Applications Turbine safety interlocks: gas / Safety signals such as steam turbine overspeed, excessive vibration, and low oil pressure are collected to trigger emergency shutdown (ESD).
Process industry safety control: In petrochemical/chemical SIS systems, signals such as emergency stop buttons, safety valve status, and flame detection are monitored to achieve safe shutdown control.
Redundant safety deployment: Dual redundancy ensures the continuity of safety functions, adapting to the high availability and safety requirements of critical equipment.
Spare parts replacement and upgrade: Adapted to the already deployed Mark VIeS system for replacing fail-safe discrete input modules, supporting automatic safety configuration recovery.
