Welcome to call for consultation: 15588722150, Manager Gao
Uses of Sibuixiang: The Sibuixiang vehicle includes the Sibuixiang soil-hauling vehicle, also known as the Sibuixiang engineering vehicle (Sibuixiang dump truck). In some places, it is also called the Sibuixiang agricultural vehicle. It is relatively flexible in movement and not as clumsy as a tractor. Since the Sibuixiang has front and rear drives and can be equipped with diesel engines of various horsepower as needed, this vehicle is very powerful and easy to use. The Sibuixiang is a vehicle similar to a “tractor”. Its main components include the steering wheel, chassis, front and rear axles, etc. This vehicle has a large loading capacity and is suitable for use in geographical environments such as mountains.
1. It uses a regular rigid steel frame for automobiles in China, which is more flexible than the traditional riveted and welded frame and remains unchanged after heavy pressure.
2. All parts are products of first-tier brands in the country, and the quality reaches the domestic level. It is easier to buy replacement parts locally in time.
3.It uses the Dongfeng130/1060axle, which is stronger and more durable than the traditional welded axle. The chassis is fully reinforced to meet the mining standards.
4. It is equipped with the Dongfeng130/140/145gearbox and comes with6It has 6 - speed high - low variable speed, which is more convenient during the walking process.
4. The whole vehicle breaks through the traditional process. The vehicle is produced in a split - type way and can be disassembled and assembled at will, which is convenient for going down the well or after - sales maintenance.
5. The steel and all screw parts are made of steel grades above National Standard 8. During the process of self - research, production and assembly, Jining Mingran Construction Machinery Co., Ltd. strictly controls the quality, which reaches the domestic level.
Model: SD - 48
20 - ton non - standard transport vehicle parameters | |
Cab type | Single - row seat/Double - row seat |
Engine | 4108Supercharged |
Gearbox | 145 Gearbox 5+1 Gears, Pneumatic Push High and Low Speeds |
Oil Cylinder | Dual Oil Cylinders |
Steering System | Hydraulic Power Steering |
Braking System | Air-Operated Parking Brake |
Drive Mode | Rear-Wheel Drive/Four-Wheel Drive |
Front Axle | 2080 |
Rear Axle | 153 |
Tire Specification | 825-20Steel Radial Tire |
Carriage Size | 3.8*2*0.6m |
Whether to Process and Customize | Yes |
Note: The product parameters are for reference only. Please consult the customer service for specific parameters.
