Engineered for Ultra-Clean Semiconductor Manufacturing Environments
Shanghai Quanbao's Stainless Steel BA Tubes deliver exceptional purity and surface integrity for critical semiconductor fabrication processes. These tubes feature a meticulously controlled bright annealed finish with surface roughness maintained below Ra 0.25μm, significantly reducing particle generation risks in sensitive cleanroom applications. Manufactured under stringent quality protocols, our tubing solutions prevent contamination that could compromise wafer yields in deposition, etching, and gas delivery systems.
Core Technical Specifications:
- Material Composition: 304/304L or 316/316L stainless steel variants
- Surface Treatment: Bright annealing under hydrogen atmosphere
- Critical Dimensions: Outer diameter 1/8" to 4" | Wall thickness 0.028" to 0.249"
- Surface Roughness: Ra ≤ 0.25μm (measurable per SEMI standards)
- Straightness Tolerance: ≤1.5mm per meter length
Performance Advantages in Semiconductor Operations:
| Feature | Benefit |
| Hydrogen-annealed surface | Eliminates oxide scaling & maintains metallic brightness |
| Controlled grain structure | Enhances corrosion resistance in chemical environments |
| Non-directional finish | Prevents particulate trap points in gas flow paths |
Precision Manufacturing Controls: Our production process includes multiple validation stages from material sourcing to final packaging. Each batch undergoes:
- Eddy current testing for wall integrity
- Laser micrometer dimensional verification
- Surface profilometer roughness mapping
- Cleanroom-grade packaging with double bagging
Applications Across Semiconductor Process Flow:
- Gas distribution systems for CVD and plasma tools
- Ultra-high purity chemical delivery lines
- Vacuum chamber components
- Analytical instrument fluid paths
Why Semiconductor Engineers Specify Our BA Tubes:
- Reduced particle counts in gas streams by ≥40% versus standard AP tubes
- Compatibility with high-temperature processes up to 800°C
- Passivation options available for enhanced corrosion resistance
- Traceable material certificates with mill test reports
Optimize Your Process Reliability Today
Minimize yield-impacting contamination with tubing engineered for semiconductor-grade purity standards. Shanghai Quanbao provides technical support for material selection and custom fabrication services to meet specific tooling requirements. Contact our engineering team for dimensional drawings, validation data sheets, and sample requests to verify performance in your application.
Frequently Asked Questions:
Q: What cleaning procedures are recommended before installation?
A: We recommend high-purity solvent rinsing followed by nitrogen purging. Baking at 150°C for 2 hours may be performed for moisture-sensitive applications.
Q: Are these tubes suitable for high-purity gas service?
A: Yes, the BA finish meets SEMI F20 specifications for surface outgassing characteristics in ultra-high purity gas systems.
Q: What documentation accompanies shipments?
A: All orders include material certificates with composition reports, roughness test data, and dimensional inspection records.
Q: Can you supply tubes with pre-installed fittings?
A> Tube end preparation and fitting assembly services are available as a value-added option upon request.
Q: What is the maximum continuous operating temperature?
A> The standard grade maintains mechanical integrity up to 800°C in inert atmospheres. Consult us for oxidizing environment specifications.
